Schneider Electric Anaconda FCC Conduit Fitting 90-Degree DN 20 M20x1.5 IP65

The Schneider Electric Anaconda FCC conduit fitting is a professional-grade 90-degree elbow connector engineered for DN 20 conduits. This component is designed to facilitate secure cable routing in industrial environments, providing a robust connection point that maintains the integrity of electrical installations. With its precise M20x1.5 thread, it ensures a stable fit for various cable management systems, offering long-term reliability and protection against environmental factors.

Advantages

This fitting stands out due to its high-quality construction and specialized design for demanding industrial applications. The 90-degree angle allows for efficient space management in tight installations, preventing sharp bends that could damage cables. Its IP65 ingress protection rating guarantees that the connection remains dust-tight and protected against water jets, ensuring that internal wiring is shielded from contaminants and moisture in harsh operating conditions.

Suitable for

• Industrial cable management systems
• Electrical installations requiring 90-degree conduit turns
• Environments where dust and water protection are essential
• Machinery and equipment wiring protection

When it may not be suitable

This fitting is specifically designed for DN 20 conduits with an M20x1.5 thread. It may not be compatible with conduit systems of different diameters or thread types. Additionally, it is not intended for use in high-pressure underwater applications or environments requiring higher ingress protection ratings such as IP68 or IP69K.

Key specifications

• Connector type: 90-degree elbow
• Conduit size: DN 20
• Thread type: M20x1.5
• Ingress protection: IP65
• Material: Industrial-grade construction

How to use

To install the fitting, ensure the conduit is cut cleanly to the appropriate length. Insert the conduit into the fitting until it is securely seated. Tighten the M20x1.5 thread into the corresponding enclosure or junction box port. Ensure that the seal is properly positioned to maintain the IP65 rating. Regularly inspect the connection to ensure it remains tight and free from mechanical stress.

What to consider before purchase

• Verify the conduit diameter matches the DN 20 specification
• Check that the mounting port supports an M20x1.5 thread
• Assess the environmental requirements to ensure IP65 is sufficient for your application

Usage recommendations

Always ensure that the conduit is fully inserted into the fitting to maintain the integrity of the IP65 seal. Avoid over-tightening the thread to prevent damage to the connector housing.
