Chassis plate SCHROFF 450D model 20860112 — metal mounting plate for rack enclosures

Chassis plate SCHROFF 450D model 20860112 is a metal mounting plate engineered for installation in rack and enclosure systems. It provides a flat, rigid surface for fastening electronic modules, PCBs, and other components, ensuring stable support and alignment inside 19" or proprietary enclosures used in industrial, telecom and server environments.

Advantages

The SCHROFF 450D chassis plate offers robust mechanical strength and dimensional stability typical of metal mounting plates, helping to maintain alignment and reduce vibration for installed equipment. Its design supports straightforward integration into standard rack architectures and proprietary enclosures, simplifying assembly and replacement procedures. The plate's material and finish are intended to withstand typical industrial operating conditions and offer reliable long-term structural support.

Suitable for

• Mounting electronic modules and printed circuit boards inside 19" rack enclosures
• Use in telecom and networking equipment racks
• Server chassis assembly and component mounting
• Industrial control cabinets and instrumentation enclosures

Key specifications

• Type: metal chassis/mounting plate for rack and enclosure systems
• Compatibility: designed for 19" and proprietary enclosure installations
• Function: provides rigid surface for securing modules, PCBs and components
• Application areas: industrial, telecom, server and control cabinet environments
• Mechanical properties: engineered for structural support and alignment of installed equipment

How to use

Install the chassis plate into the enclosure following the rack or enclosure manufacturer’s mounting guidelines. Position the plate at the required U-height and secure it using the appropriate fasteners for the enclosure rails or mounting points. After securing the plate, attach electronic modules, PCBs or subassemblies using compatible screws, standoffs or brackets to ensure proper spacing and grounding as required by the equipment design. Verify alignment and tighten fasteners to the torque values recommended by the component manufacturers.

Usage recommendations

Inspect the enclosure and mounting points before installation to confirm compatibility. Use corrosion-resistant fasteners if the equipment operates in humid or corrosive environments, and follow ESD, grounding and safety procedures when mounting electronic assemblies.
