Cabinet SCHROFF C-Rail F.800W 650L 4U — SCHROFF rack cabinet, 800 mm width, 650 mm depth, 4U mounting

SCHROFF C-Rail Cabinet F.800W 650L 4U is a compact rack cabinet engineered to accommodate 4U equipment in environments that require an 800 mm internal width and 650 mm internal depth. The cabinet supports standard rail-mounted components and provides a rigid frame for secure mounting of servers, network devices and industrial electronics. Its compact footprint is intended for server rooms, network closets and industrial installations where space-efficient, stable and organized equipment installation is needed.

Advantages

The SCHROFF C-Rail design delivers robust mechanical support through welded frame elements and adjustable mounting rails, ensuring reliable load distribution for 4U devices. The 800 mm width and 650 mm depth dimensions enable installation of wider network and industrial equipment while maintaining a compact external footprint. The cabinet facilitates tidy cable routing and predictable airflow paths, contributing to easier maintenance and reduced installation time.

Suitable for

• Mounting a single 4U server or network appliance in limited-space racks or closets
• Industrial control cabinets requiring rail-mounted electronics with standardized mounting
• Edge computing or telecom enclosures where a compact, wide-format chassis is necessary
• Cabinetized installations that need structured cable management and secure mounting

Key specifications

• Mounting height: 4U
• Internal width: 800 mm
• Internal depth: 650 mm
• Mounting: standard rail-mounted 19" compatible rails (adjustable position)
• Construction: steel frame with reinforced mounting rails
• Cable management: guided entry points and internal routing options
• Cooling support: unobstructed front-to-rear airflow path for forced or passive cooling

How to use

Place the SCHROFF C-Rail cabinet on a level surface or within a compatible rack bay and secure it according to local installation rules. Adjust the 19" mounting rails to align with the equipment's mounting holes, then fasten the 4U device using appropriate rack screws and cage nuts. Route power and data cabling through the designated entry points and secure cables to the cabinet's internal routing features to maintain clear airflow and service access. Verify that installed equipment has sufficient clearance for connectors and cooling.

Usage recommendations

For optimal performance, install the cabinet in a ventilated environment and, when necessary, use directed fans or the data center's cooling infrastructure to maintain equipment temperature. Use appropriate earthing and cable strain relief, and follow manufacturer guidelines for load distribution to prevent overloading the mounting rails.
