Cover plate SCHROFF EMC 84HP 295D, kit of 2 pieces

The Cover plate SCHROFF EMC 84HP 295D, kit of 2 pieces is a pair of front/rear blanking plates designed for SCHROFF rack and chassis systems. Each plate covers an 84HP module width with a 295D depth profile to close unused openings, provide basic mechanical protection and support electromagnetic compatibility within a rack or enclosure. Supplied as a set of two, these plates are intended for installations where unused front or rear slots must be sealed to control airflow, reduce ingress of dust and debris, and maintain EMC continuity across device bays.

Advantages

These SCHROFF cover plates are manufactured to fit the profile and mounting scheme of compatible SCHROFF systems, ensuring a precise fit and consistent contact surfaces for EMC performance. By blanking unused apertures, the plates aid in directing airflow through active modules, reduce the risk of accidental contact with internal components during handling, and contribute to mechanical protection during assembly and transport. The two-piece kit provides a complete pair for front and rear closure or for use in two separate locations as needed.

Suitable for

• Closing unused 84HP openings in SCHROFF racks or chassis
• Maintaining airflow routing and cooling efficiency in populated enclosures
• Improving EMC continuity between modules and subracks
• Protecting internal components from dust, debris and mechanical damage during transport or assembly

When it may not be suitable

This kit is intended specifically for systems using the 84HP width and 295D depth profile; it may not fit other manufacturers’ profiles or non-standard panel configurations. The plates provide passive EMC support and mechanical closure but are not a substitute for dedicated filtering components, gaskets, or active electromagnetic shielding solutions where stringent EMC requirements exist.

Key specifications

• Pack quantity: 2 plates per kit
• Panel width coverage: 84HP (module width standard)
• Depth profile: 295D
• Primary functions: blanking/closure, airflow management, basic EMC continuity, mechanical protection
• Compatibility: designed for SCHROFF rack and chassis systems matching the 84HP x 295D profile

How to use

Install the cover plate by aligning it with the target front or rear opening of the SCHROFF rack or chassis that matches the 84HP by 295D profile. Secure the plate using the chassis’ standard mounting points or fasteners provided by the enclosure; ensure contact surfaces are clean and free from paint or debris for optimal mechanical and EMC continuity. Use one plate to close a single opening, or both plates to close front and rear positions or two separate locations. For transport, verify all plates and fasteners are tightened to prevent movement within the enclosure.

What to consider before purchase

• Confirm the enclosure or module uses the 84HP width and 295D depth profile compatible with SCHROFF systems
• Determine whether passive cover plates meet your EMC and cooling requirements or if additional shielding or filters are necessary
• Check mounting method and required fasteners on your chassis to ensure straightforward installation

Usage recommendations

For effective airflow control and EMC performance, use the cover plates in combination with properly installed active modules and ensure front-to-rear cooling paths are maintained. Inspect contact surfaces periodically and replace plates if bent or damaged to preserve mechanical protection and shielding continuity.
