Rack mount enclosure SCHROFF BGTR H M.GR.6HE 84TE 355T KD — 6U, 84 TE, depth 355 mm

Rack mount enclosure SCHROFF BGTR H M.GR.6HE 84TE 355T KD is a 6U industrial subrack designed for modular electronic assemblies. It offers a standardized 84 TE front mounting width and an internal depth of 355 mm, providing space for plug-in cards, power supply modules, backplanes and I/O interfaces. The enclosure is intended for installation in 19-inch rack systems and is constructed to meet the mechanical and thermal requirements of telecom, industrial control and test equipment environments.

Advantages

The enclosure combines a compact 6U height with a wide 84 TE front area, enabling high module density in a limited rack unit. Robust sheet-metal construction and reinforced mounting rails ensure stable module support and vibration resistance. The 355 mm internal depth accommodates a broad range of standard subrack modules and power supplies while keeping overall installation depth moderate. Front mounting rails and panel provisions permit standardized card retention and easy front access for maintenance and configuration.

Suitable for

• Telecommunications equipment and shelf-mounted line cards
• Industrial automation controllers and I/O aggregation
• Laboratory and test instrumentation with modular plug-in units
• Embedded computing and communication gateway assemblies

Key specifications

• Format: 6U rack height suitable for 19-inch rack installation
• Front mounting width: 84 TE for modular card mounting
• Internal depth: 355 mm for subrack modules and power units
• Construction: sheet-metal housing with reinforced mounting rails
• Access: front-access mounting and removable panels for maintenance

How to use

Install the enclosure into a compatible 19-inch rack using appropriate rack screws and mounting hardware. Fit modular plug-in cards, power modules and backplane connectors into the 84 TE front area and secure them to the mounting rails. Route internal cabling to maintain clear airflow and prevent interference with modules. Close removable panels once modules and connectors are installed, and verify mechanical retention and electrical connections before powering the system.

Usage recommendations

For reliable operation, select modules and power supplies that match the 355 mm internal depth and the 84 TE mounting pitch. Ensure adequate rack ventilation and consider front-to-rear or rear-to-front airflow based on installed components. Use proper grounding and rack bonding practices to maintain electromagnetic compatibility and operator safety.
