Guide rail accessory SCHROFF 24568-381, length 280 mm

Guide rail accessory SCHROFF 24568-381, length 280 mm is a precision-machined guide rail intended for mounting and guiding modules or components within equipment racks and chassis. It provides a straight, stable path for insertion and extraction of units, ensuring alignment and reducing wear on connector interfaces. The guide rail is suitable for server, telecom and industrial enclosures that accept SCHROFF guide rails and is designed to integrate with standard rack and chassis mounting points.

Advantages

This guide rail offers accurate linear support and repeatable alignment to simplify installation and maintenance of hot-swappable or slide-in modules. Its 280 mm length is optimized for mid-depth chassis, providing reliable engagement without occupying excess space. The rail reduces mechanical stress on module edges and connectors during operation and helps maintain consistent airflow and component positioning within the enclosure.

Suitable for

• Mounting and guiding plug-in modules in server racks
• Telecom chassis that require slide-in module support
• Industrial enclosures with compatible guide rail interfaces
• Maintenance workflows involving frequent module insertion and removal

Key specifications

• Length: 280 mm
• Function: guide and support for sliding modules and components
• Compatibility: designed for systems accepting SCHROFF guide rails
• Application environment: server, telecom and industrial chassis
• Mechanical behavior: provides linear alignment and reduces connector wear

How to use

Install the guide rail by aligning it with the chassis mounting points and fastening it according to the enclosure manufacturer’s instructions. Slide the module along the rail to verify smooth engagement and proper alignment with the mating connectors. Ensure the rail is secured at both ends and that any retaining clips or screws are tightened to prevent lateral movement. Periodically inspect the rail and mounting hardware for deformation or wear and re-tighten fasteners as needed.

Usage recommendations

Use appropriate fasteners and torque settings recommended by the equipment manufacturer. Avoid bending or applying excessive lateral force during module insertion. For environments with heavy dust or particulate, perform routine cleaning to prevent debris accumulation on the rail surface and sliding interfaces.
