Rack accessory SCHROFF RATIOPAC AIR 19" 3/4U 84HP 315D

SCHROFF RATIOPAC AIR 19" 3/4U 84HP 315D is a rack accessory intended for standard 19-inch equipment cabinets. The unit occupies 3/4U of rack height, offers 84 horizontal pitch (HP) and a depth of 315 mm. It is designed to accommodate small modules, interface panels or compact power distribution units while supporting organized cable routing and maintaining airflow within the cabinet.

Advantages

The RATIOPAC AIR provides a compact, standardized mounting option that preserves front-to-back airflow thanks to its 315 mm depth and an open layout tailored for small components. Its 84HP width enables multiple connection points in minimal rack space and simplifies integration with existing 19" rail systems. The accessory is compatible with common server-room configurations and helps reduce clutter by centralizing small devices in one accessible location.

Suitable for

• Mounting compact interface panels and patch modules
• Installing small power distribution units (PDUs) or surge protectors
• Organizing patching and cable entry points in network closets
• Hosting monitoring or control modules that require limited rack depth

Key specifications

• Rack standard: 19-inch
• Height: 3/4U
• Width: 84 HP (horizontal pitch)
• Depth: 315 mm
• Intended use: accessory for mounting small modules, PDUs or panels

How to use

Install the RATIOPAC AIR into standard 19" rack rails at the desired vertical position, securing it with suitable rack screws. Mount modules, interface panels or compact PDUs within the 84HP width and align cabling toward existing cable management paths. Ensure components are fastened to prevent movement during service and verify that installed devices do not obstruct airflow through adjacent rack units.

Usage recommendations

Place heat-generating modules toward the front or rear as appropriate to the cabinet's airflow design, and avoid stacking devices that exceed the 315 mm depth. Use proper earthing and follow rack manufacturer's mounting torque specifications. Regularly inspect cable routing to maintain unobstructed ventilation and to simplify maintenance tasks.
