Fan unit SCHROFF 84HP 220D CPL. (model 24572411) axial cooling module

Replacement fan unit SCHROFF 84HP 220D CPL. (model 24572411) axial cooling module is designed for forced-air cooling in 84HP enclosures with 220V D specification. The module provides directed airflow to dissipate heat from electronic boards, power supplies and rack-mounted components. It integrates into SCHROFF systems and similar chassis that accept 84HP axial fan modules and is intended to maintain stable operating temperatures in server cabinets, industrial electronics and telecommunication equipment.

Advantages

This axial cooling module delivers continuous airflow with a compact form factor suited to modular rack systems. Its construction is compatible with standard 84HP mountings and electrical supply at 220V, enabling straightforward replacement or upgrade of existing fan assemblies. The unit reduces hotspot formation inside enclosures and supports consistent ventilation for components sensitive to elevated temperatures. Designed for integration into rack or chassis installations, the fan module offers predictable cooling performance and ease of installation.

Suitable for

• 84HP SCHROFF enclosures and compatible rack modules requiring axial forced-air cooling
• Server cabinets and blade chassis where space-efficient fan replacement is needed
• Industrial electronic racks and control cabinets with 220V supply
• Telecommunication equipment and network infrastructure requiring continuous ventilation

Key specifications

• Form factor: 84HP axial fan module designed for modular rack/chassis integration
• Operating voltage: suitable for 220V systems
• Cooling method: forced-air axial flow for directed ventilation
• Mounting: front-accessable module for insertion into compatible 84HP mounting frames
• Application environment: server racks, industrial cabinets, telecom enclosures

How to use

Switch off power to the enclosure before attempting replacement. Remove the existing fan module from the 84HP slot following the enclosure manufacturer’s instructions, then insert the SCHROFF axial cooling module into the same slot and secure it according to the chassis mounting points. Connect the electrical supply in accordance with the system wiring and safety standards for 220V equipment. After installation, restore power and verify airflow and fan operation, monitoring temperature and vibration briefly to confirm proper integration.

Usage recommendations

Ensure periodic inspection of the fan inlet and outlet for dust buildup and clean as needed. For reliable operation, verify that the enclosure’s airflow path is not obstructed and maintain ambient conditions within equipment specifications. If used in noise-sensitive environments, consider acoustic dampening measures or check for lower-noise fan alternatives that are compatible with 84HP mountings.
