Rear wall foot SCHROFF RUECKWANDFUSS 4HE RAL7016 with rubber insert

Rear wall foot SCHROFF RUECKWANDFUSS 4HE RAL7016 with rubber insert is a mounting support for enclosures and racks designed to provide stable rear support for 4U (4HE) rear panels. Finished in RAL7016, the component integrates a rubber insert that cushions equipment, reduces vibration transfer and protects cabinet surfaces from wear. The foot is intended for use with server racks, electronic cabinets and industrial housings where a firm yet slightly flexible support point is required.

Advantages

The rubber insert offers vibration dampening and surface protection, reducing the risk of component wear and noise transmission. The RAL7016 finish ensures consistent appearance and corrosion resistance suitable for typical data centre and industrial environments. The 4HE dimensioning aligns with standard 4U rear panels to ensure compatible mounting and reliable load distribution at the rear of the enclosure.

Suitable for

• Server racks and network cabinets requiring rear support for 4U units
• Electronic enclosures where vibration reduction is needed
• Industrial housings and telecommunication cabinets
• Retrofit installations to protect cabinet panels and equipment surfaces

Key specifications

• Intended panel height: 4HE (4U) rear panels
• Finish colour: RAL7016 (anthracite grey)
• Integrated rubber insert for cushioning and vibration damping
• Mounting: rear wall support for equipment enclosures and racks
• Function: provides stable rear support and protects contact surfaces

How to use

Install the rear wall foot by aligning it with the rear panel mounting points of the enclosure and securing it according to the cabinet's fastening method. Ensure the rubber insert is positioned between the metal foot and the equipment contact surface to achieve vibration isolation and surface protection. Verify that the support bears the load evenly across the 4HE section and that all mounting hardware is tightened to the enclosure manufacturer's torque recommendations.

Usage recommendations

For optimal performance, check compatibility with the enclosure's rear panel layout before installation. Periodically inspect the rubber insert for signs of wear or hardening and replace if cushioning performance degrades. Use in environments within the equipment manufacturer's recommended temperature and humidity ranges to preserve the rubber properties and finish quality.
