Hinge bracket SCHROFF 7021, 60 mm mounting depth, metal support for enclosure panels

Hinge bracket SCHROFF 7021 is a metal support element with a 60 mm mounting depth designed for installation in electronic enclosures and rack-mounted systems. It functions as a mounting and alignment point for hinged panels and doors, enabling secure attachment and reliable pivoting. The bracket is intended for use in industrial cabinets, server racks and equipment housings where controlled access and component protection are required.

Advantages

The SCHROFF 7021 hinge bracket is built from metal to provide mechanical strength and dimensional stability during repeated opening and closing cycles. Its 60 mm mounting depth allows compatibility with common enclosure layouts and provides sufficient engagement for various panel thicknesses. The precise geometry facilitates correct alignment of doors and reduces play, helping to maintain sealing and protective properties of enclosures. The simple mounting design supports straightforward installation and replacement during maintenance operations.

Suitable for

• Mounting hinged panels and doors in server racks and network cabinets
• Access panels and maintenance doors in industrial control cabinets
• Replacement of worn or damaged hinge supports in electronic housings
• Applications requiring robust metal brackets with moderate mounting depth

Key specifications

• Material: metal construction for mechanical strength
• Mounting depth: 60 mm
• Function: support and alignment for hinged panels and doors
• Intended environment: rack-mounted systems, enclosures and industrial cabinets
• Installation: designed for fixed mounting to enclosure frame or panel

How to use

Position the hinge bracket at the intended mounting location on the enclosure frame or panel, ensuring the 60 mm engagement corresponds with the panel geometry. Secure the bracket using appropriate fasteners compatible with the enclosure and bracket holes. Align the mating panel or door on the hinge pivot and verify smooth opening and closing without binding. Check clearances and, if necessary, adjust fastener torque or bracket position to achieve optimal alignment and sealing.

Usage recommendations

For reliable operation, select fasteners and sealing elements that match the enclosure material and environmental requirements. Inspect hinge brackets periodically for signs of wear or corrosion and replace if deformation or excessive play appears. When used in server and network cabinets, maintain proper cable and equipment clearance to avoid interference with hinge movement.
