Mounting plate SCHROFF 42TE 220T model 34563014 for 19"/rack installations

Mounting plate SCHROFF 42TE 220T model 34563014 for 19"/rack installations is a metal mounting accessory engineered for integration into standard 19-inch rack systems. The plate offers a 42TE usable width and 220T mounting spacing, providing a stable platform for securing electronic modules, plug-in cards and mechanical subassemblies inside server, telecom and industrial enclosures. Constructed to match common rack hole patterns and spacing, the plate supports reliable alignment and fastening of components in professional installations.

Advantages

The SCHROFF mounting plate delivers robust mechanical support and compatibility with standard 19" racks. Its defined 42TE width and 220T spacing simplify planning and installation of front-panel modules and internal assemblies. The metal construction contributes to structural integrity and grounding potential when secured within a rack cabinet, while the precise hole pattern ensures repeatable mounting positions for maintenance and upgrades.

Suitable for

• Mounting front-panel modules and plug-in cards in 19" rack enclosures
• Server and telecom rack cabinets requiring standardized mounting spacing
• Industrial control cabinets where durable, rack-compatible plates are needed
• Prototyping and integration tasks that need repeatable, aligned mounting points

Key specifications

• Mounting width: 42TE (42 rack units of TE width)
• Mounting spacing: 220T standard pitch for plug-in modules
• Form factor: metal plate compatible with 19" rack systems
• Typical compatibility: server, telecom and industrial rack enclosures
• Function: mechanical support, alignment and grounding when installed

How to use

Install the mounting plate into the 19" rack by aligning the plate with the rack’s vertical mounting rails and fastening it using appropriate rack screws or captive nuts. Position modules or components on the plate according to the 42TE width and 220T spacing, then secure each device using the recommended fasteners. Ensure the plate is seated firmly and that all connections and guide rails are aligned before powering equipment. Follow any additional enclosure or system instructions for grounding and cable routing.

Usage recommendations

For reliable performance, use screws and nuts recommended for 19" racks and verify compatibility with the specific enclosure model. When installing active equipment, confirm sufficient ventilation and load distribution across multiple mounting points. For grounding continuity, bond the plate to the rack frame according to site grounding practices.
