Wall mounted rack ROLINE 26.21.0122 19U Grey 80 kg IP20

The ROLINE 26.21.0122 wall-mounted rack is a 19U enclosure for indoor network installations. Constructed from powder-coated sheet steel (grey RAL 7035), it offers an IP20 protection rating and a maximum load capacity of 80 kg while weighing 9.8 kg. The cabinet includes a punched cable inlet in the base plate and roof, an area in the roof for an optional fan module, and adjustable galvanised profile rails compatible with 483 mm (19") mounting. Side panels are removable with quick-release fasteners and can accept an optional lock. Wall mounting is performed by attaching the rear panel to the wall and then connecting the housing; optional levelling feet or castors allow conversion to a free-standing cabinet.

Advantages

The rack provides a compact 19U installation with a favourable balance between robustness and compactness, combining adjustable depth rails and pre-punched cable inlets for flexible cabling. Powder-coated steel construction ensures mechanical strength and corrosion resistance, while removable side panels improve accessibility for installation and maintenance. The roof provision for a fan module and the option to add levelling feet or castors increase adaptability for different deployment scenarios.

Suitable for

• Small to medium-sized network cabinets in offices and server rooms
• Mounting switches, patch panels and 19" active or passive equipment
• Indoor installations where a compact wall-mounted 19U rack is required

Key specifications

• Model: ROLINE 26.21.0122
• Mounting size: 19", 483 mm rails, 19U
• Maximum load capacity: 80 kg
• Weight: 9.8 kg
• Material and finish: sheet steel, powder-coated (RAL 7035 grey)
• Protection rating: IP20 (indoor use)
• Features: punched cable inlets (base and roof), roof cutout for fan module, adjustable depth galvanised profile rails, removable side panels with quick-release fastener
• Brand / MPN / EAN: Secomp / 26.21.0122 / 7630049601253

How to use

Install the rear panel on a suitable load-bearing wall using appropriate fixings, then hang and secure the cabinet housing to the mounted rear panel. Adjust the depth of the galvanised profile rails to match the depth of your 19" equipment and mount devices using standard 19" fasteners. Route cables through the punched inlets in the base plate or roof; if active cooling is required, install a compatible fan module in the roof cutout. Remove side panels via the quick-release fasteners when accessing the interior for installation or maintenance. If a free-standing setup is needed, fit optional levelling feet or castors.

Usage recommendations

For safe operation and long service life, install the rack on a structurally sound wall, observe the 80 kg maximum load limit, and ensure proper ventilation for heat-generating equipment. Use appropriate mounting hardware for your wall type and secure heavy devices as low as possible in the cabinet to maintain stability.
