Interactive flat panel Sharp PNL752B 75" LCD 4K Ultra HD 3840 x 2160

USB 2.0 Type-B ports quantity:

1

Display

Display diagonal: iagonal of the visible part of the screen expressed in centimeters and inches.

75 "

Display technology:

LCD

HD type:

4K Ultra HD

Panel type:

VA

Display resolution:

3840 x 2160

Response time:

8.5 ms

Contrast ratio (typical):

5000:1

Display brightness:

400 cd/m²

Viewing angle, vertical:

178 °

Viewing angle, horizontal:

178 °

Display diagonal (metric):

189.3 cm

Supported graphics resolutions:

640 x 480 (VGA), 720 x 480, 720 x 576, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 960, 1360 x 768 (WXGA), 1440 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 1920 x 720, 3840 x 2160, 4096 x 2160

Native aspect ratio:

16:9

Multi-touch:

Yes

Backlight type:

LED

Touchscreen:

Yes

Anti-glare screen:

Yes

LED backlight:

Yes

Touchscreen technology:

Hybrid Precision

Active display area (W x H):

1650.2 x 928.3

Surface hardness:

8

LED backlighting type:

Direct-LED

Number of simultaneous touchpoints:

20

Haze rate:

8 %

Design

Screen shape:

Flat

Product colour:

Black

Placement supported:

Indoor

Panel mounting interface:

800 x 400

Product design:

Interactive flat panel

Mounting type:

Wall

Bezel width (side):

16.8 mm

Bezel width (top):

16.8 mm

Bezel width (bottom):

45.7 mm

Orientation:

Horizontal/Vertical

Ports & interfaces

HDMI ports quantity:

3

Ethernet LAN (RJ-45) ports:

1

Microphone in:

Yes

RS-232 interface:

Yes

USB version:

2.0/3.2 Gen 1 (3.1 Gen 1)

VGA (D-Sub) input ports:

1

USB ports quantity:

8

USB port:

Yes

RS-232C:

Yes

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity:

4

USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity:

1

USB Type-C DisplayPort Alternate Mode:

Yes

USB Power Delivery (USB PD):

Yes

OPS module slot:

Yes

HDMI input ports quantity:

3

USB Power Delivery up to:

65 W

Ergonomics

Wall mountable:

Yes

VESA mounting:

Yes

Audio

Built-in speaker(s):

Yes

Performance

HDCP:

Yes

Purpose:

Corporate

Operating system installed:

Android

Operating hours (hours/days):

16/7

Writing tools:

Finger, Passive pen

Network

Ethernet LAN:

Yes

Wi-Fi:

Yes

Ethernet LAN data rates:

100

Wi-Fi standards:

802.11a, 802.11b, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)

Multimedia

RMS rated power:

20 W

Technical details

Internal memory:

4000 MB

OPS slot:

1

Compliance certificates:

CE, REACH, RoHS

Computer system

Operating system version:

9

Windows operating systems supported:

Windows 10 Education, Windows 7, Windows 8, Windows Vista, Windows XP

Mac operating systems supported:

Mac OS X 10.0 Cheetah

Internal storage capacity:

32 GB

Internal memory:

4 GB

Computer system:

Yes

Other features

Bluetooth version:

5.0

Bluetooth:

Yes

USB 2.0 ports quantity:

1

Headphone outputs:

1

Audio input:

1 x 3,5 mm jack

Audio output:

1 x 3,5 mm jack

USB connector type:

USB Type-A, USB Type-B, USB Type-C

Mobile operating systems supported:

Android

Weight (without stand):

49500 g

Height (without stand):

1019.8 mm

Depth (without stand):

85.7 mm

Power

Power consumption (typical): Power consumption in switched-on state expressed in W.

230 W

Power consumption (max):

400 W

AC input frequency:

50 - 60

AC input voltage:

100-240

Weight & dimensions

Bezel width:

45.7 mm

Operational conditions

Operating relative humidity (H-H):

20 - 80

Operating temperature (T-T):

5 - 35

Packaging content

Remote control included:

Yes

Cables included:

AC, HDMI, USB

Batteries included:

Yes

Packaging data

Package weight:

62000 g

Package depth:

225 mm

Package height:

1155 mm

Package width:

1863 mm

Logistics data

Harmonized System (HS) code:

85285210
