Dimensions (WxDxH):
Dimensions of the product (Width x Depth x Height).
-
19 x 69 x 94
-
Weight:
Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies.
-
0.075 kg
-
Power consumption (typical):
Amount of power consumed by this model, often expressed in watts (W). Typical values that manufacturers give are power consumption when off, standby/suspended mode, typical use, maximum usage.
-
0.3 W
-
Operating relative humidity (H-H):
-
30 - 70
-
Operating temperature (T-T):
The minimum and maximum temperatures at which the product can be safely operated.
-
-20 - 40
-
LED indicators:
-
Yes
-
Product colour:
The colour e.g. red, blue, green, black, white.
-
Black
-
Frequency band:
A small section of the spectrum of radio communication frequencies, in which channels are usually used or set aside for the same purpose e.g.for a channel on FM radio; for mobile networks to communicate with mobile phones.
-
868.4
-
Overload protection:
-
Yes
-
Channels quantity:
The number of channels the device has. There can be an individual input or output for each channel.
-
2 channels
-
Overheat protection:
-
Yes
-
Maximum current:
The greatest possible amount of current, which is a quantity representing the rate of flow of electric charge.
-
25 A
-
Housing material:
What the casing of the product is made of.
-
Plastic
-
Remotely operated:
The device can be controlled by remote control, which is a device that controls an apparatus by means of radio or infrared signals.
-
Yes
-
AC input frequency:
-
50/60
-
AC input voltage:
The voltage of the AC electricity that is inputted into the product.
-
110 - 240
-
Maximum indoor range:
The maximum distance to which the signals are transmitted, when the device is used indoors.
-
40 m
-
Number of modules:
-
1
-
DIN rail mounting:
-
Yes
-
Cable section:
-
0.5 - 2.5
-
Product type:
The sub-category of the product.
-
Smart relay
-
Transmit power:
-
25 mW
-
Transmission range:
-
0 - 40
-
Weekly schedule:
-
Yes
-
Integrated energy meter:
-
Yes
