Weight:
Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies.
-
0.471 kg
-
Operating relative humidity (H-H):
-
0 - 95
-
Storage temperature (T-T):
The minimum and maximum temperatures at which the product can be safely stored.
-
-40 - 70
-
Package weight:
Weight of the packaged product.
-
454 g
-
Operating temperature (T-T):
The minimum and maximum temperatures at which the product can be safely operated.
-
-25 - 40
-
Height:
The measurement of the product from head to foot or from base to top.
-
85 mm
-
Input voltage:
The voltage (V) which is required to power the product.
-
400
-
Width:
The measurement or extent of something from side to side.
-
72 mm
-
Depth:
The distance from the front to the back of something.
-
72 mm
-
Rated current:
-
16 A
-
Input frequency:
The frequency (Hz) which is required to power the product.
-
50
-
Country of origin:
Country where the device is made. Aka Country of manufacture (COM).
-
Portugal
-
Input current:
-
16
-
Package depth:
The distance from the front to the back of the packaging.
-
96 mm
-
Package height:
The distance from the top to the bottom of the packaging.
-
82 mm
-
Package width:
The distance from one side of the packaging to the other.
-
40 mm
-
Minimum order quantity:
-
1 pc(s)
-
International Protection (IP) code:
The IP code classifies and rates the degree of protection provided against the intrusion (including body parts such as hands and fingers), dust, accidental contact, and water by mechanical casings and electrical enclosures. It is published by the International Electrotechnical Commission (IEC). The digits (characteristic numerals) indicate conformity with the conditions summarized in the tables below. Where there is no protection rating with regard to one of the criteria, the digit is replaced with the letter X. an electrical socket rated IP22 is protected against insertion of fingers and will not be damaged or become unsafe during a specified test in which it is exposed to vertically or nearly vertically dripping water. Another example is the Sony Xperia Z Ultra, one of the first cellular phones to be IP-rated; it is rated at IP58 and marketed as "dust resistant" and can be "immersed in 1.5 meter of freshwater for up to 30 minutes".
-
IP20
-
Mounting depth:
The distance between where the back of the device is mounted to (usually the wall) and the front of the device.
-
70 mm
-
Breaking capacity:
-
6 A
-
Number of poles:
-
4
-
Installation type:
The way in which the product is being installed.
-
DIN-rail
-
Rated voltage:
-
400 V
-
Quantity per pack:
-
1 pc(s)
-
Ambient temperature range:
-
-25 - 40
-
Overvoltage category:
-
CAT III
-
Battery included:
-
No
-
Pollution degree:
-
3
-
Circuit breaker type:
-
Residual-current device with overcurrent protection (RCBO)
-
Power dissipation:
-
2.3 W
-
Interlocking:
-
Yes
-
Doesn't contain:
-
Halogen, Silicone
-
Total power loss:
-
2.3 W
-
Residual-current type:
-
Type A
-
Trip curve type:
-
Type C
-
Rated impulse withstand voltage (Uimp):
-
4 kV
-
Compliance certificates:
Indicates which regulatory, safety, and environmental standards the product complies with, as verified by recognized authorities or certification bodies.
-
CE, RoHS, REACH
-
Disconnection characteristic:
-
Undelayed
-
Number of modular spacings:
-
4
-
Voltage type:
-
AC
-
Release characteristic:
-
C
-
Connectable solid conductor cross-section:
-
1 - 35
-
Connectable stranded conductor cross-section:
-
1 - 35
-
Switching neutral conductor:
-
Yes
-
Rated insulation voltage (Ui):
-
500 V
-
Rated short-circuit breaking capacity (IEC 60947-2):
-
6 kA
-
Number of protected poles:
-
4
-
Current limiting class:
-
Class 3
-
Leakage current type:
-
A
-
Rated fault current:
-
30 mA
-
Anti-nuisance tripping version:
-
Yes
-
Surge current capacity:
-
0.25 kA
-
Mounting method:
-
DIN rail mounted
