Socket-outlet Siemens 6GK1901-1BB10-2AA0 — PCB mount; weight 30 g; dimensions 5.3×3.3×6.2 mm

The Siemens socket-outlet is a compact PCB-mounted connector designed for use in electronic assemblies where a small board-mounted socket connection is required for signal or power interfacing. With a lightweight construction and a small footprint, this socket-outlet is intended to integrate into densely packed circuit boards while providing a reliable interface point for mating components or wiring harnesses.

Advantages

This PCB mount socket-outlet offers a low-profile form factor and minimal weight, making it suitable for applications with strict space and mass constraints. Its standardized rectangular package and precise dimensions facilitate reproducible placement during PCB assembly and soldering processes. The component's modest size supports high-density layouts without significantly increasing board area or obstructing nearby components.

Suitable for

• Signal and low-power connections on printed circuit boards
• Embedded electronics in compact devices and control modules
• Prototyping and small-series assemblies where board space is limited

Key specifications

• Mounting type: PCB mount
• Weight: 30 g
• Package dimensions (W × D × H): 5.3 × 3.3 × 6.2 mm
• Form factor: compact, rectangular package suitable for dense layouts

How to use

Position the socket-outlet on the PCB according to the board layout and footprint design that matches the package dimensions. Secure the component using standard soldering techniques appropriate for the board and assembly process, ensuring correct orientation and reliable solder joints. After assembly, verify electrical continuity and mechanical seating before integrating mating connectors or applying signals and power.

Usage recommendations

Ensure the PCB footprint and solder mask openings match the socket-outlet dimensions to avoid misalignment. Verify thermal profiles for soldering to prevent thermal stress, and inspect solder joints visually or with X-ray for high-reliability applications.
