Horizontal scan range:
-
15 - 93
-
Vertical scan range:
-
23 - 63
-
Weight:
Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies.
-
13 kg
-
Power consumption (typical):
Amount of power consumed by this model, often expressed in watts (W). Typical values that manufacturers give are power consumption when off, standby/suspended mode, typical use, maximum usage.
-
378 W
-
Zoom capability:
The amount that the camera lens can zoom.
-
No
-
Operating relative humidity (H-H):
-
20 - 80
-
Storage temperature (T-T):
The minimum and maximum temperatures at which the product can be safely stored.
-
-10 - 60
-
Focus:
-
Auto/Manual
-
Operating temperature (T-T):
The minimum and maximum temperatures at which the product can be safely operated.
-
0 - 45
-
Projection technology:
-
3LCD
-
Projector brightness:
-
6000 ANSI lumens
-
Serial interface type:
-
RS-232C
-
Ethernet LAN:
An Ethernet LAN (Local Area Network) interface is present, for a wired conection via a cable.
-
No
-
Storage relative humidity (H-H):
-
20 - 80
-
Power source:
What is providing power for the product e.g. mains electricity.
-
AC
-
Height:
The measurement of the product from head to foot or from base to top.
-
169 mm
-
Analog signal format system:
The supported protocols for exchanging analog signals.
-
SECAM, PAL N, PAL M, PAL 60, PAL, NTSC 4.43, NTSC 3.58
-
Width:
The measurement or extent of something from side to side.
-
460 mm
-
Depth:
The distance from the front to the back of something.
-
494 mm
-
Product colour:
The colour e.g. red, blue, green, black, white.
-
Black
-
Noise level:
The amplitude level of the undesired background noise, usually measured in decibels (db).
-
36 dB
-
Heat dissipation:
The heat generated by the power supply.
-
1290 BTU/h
-
Throw ratio:
-
1.39:1 - 2.23:1
-
Zoom ratio:
Measures how much the camera can adjust its focus for distance shots. A 3x zoom ratio changes the camera's focal length by a factor of three, from 35 mm to 105 mm for example.
-
1.6:1
-
Power consumption (standby):
The amount of electricity that is consumed when the product is on standby.
-
0.5 W
-
Ethernet LAN (RJ-45) ports:
Number of Ethernet LAN (RJ-45) ports (connecting interfaces) in the device. Ethernet LAN (RJ-45) ports allow a computer to connect to the ethernet.
-
1
-
DVI port:
Digital Visual Interface (DVI) is a video display interface to connect a video source to a display device, such as a computer monitor.
-
No
-
VGA (D-Sub) ports quantity:
Number of VGA (D-Sub) ports (connecting interfaces) in the device. The VGA (D-Sub) connector is a 15 pin connector between a computer and a monitor. It was first introduced in 1987 by IBM.
-
1
-
Screen size compatibility:
The different screen sizes which the device can work with.
-
1016 - 15240
-
Built-in speaker(s):
The device contains speaker(s) to produce sound.
-
No
-
Full HD:
Full High Definition (HD) means that a display supports a resolution of 1920 x 1080 pixel, and has a digital TV connection.
-
No
-
S-Video inputs quantity:
The number of ports (input sockets) for S-Video, which is a signalling standard for standard definition video, typically 480i or 576i.
-
1
-
Wi-Fi:
Popular technology that allows an electronic device to exchange data or connect to the internet wirelessly using radio waves.
-
No
-
Card reader integrated:
A card reader is a device that enables reading and, in some cases, writing data to and from a memory card.
-
No
-
Composite video in:
The socket (port) for the composite video input (white cable).
-
1
-
PC in (D-Sub):
The socket (port) to receive input from a PC via a D-sub, which is a connector with a characteristic D-shaped metal shield.
-
No
-
PC Audio in:
The socket (port) for the PC audio input.
-
No
-
Component video (YPbPr/YCbCr) in:
The number of sockets (ports) for RF (radio frequency) connections into the product.
-
1
-
HDMI ports quantity:
The number of sockets (ports) for HDMI connections. HDMI (High-Definition Multimedia Interface) is a compact audio/video interface for transferring uncompressed video data and compressed/uncompressed digital audio data from a HDMI-compliant device ("the source device") to a compatible computer monitor, video projector, digital television, or digital audio device. HDMI is a digital replacement for existing analog video standards.
-
1
-
Ethernet LAN data rates:
The different speed levels of the Ethernet LAN connection.
-
100, 10
-
Keystone correction, vertical:
-
30
-
Keystone correction, horizontal:
-
30
-
Supported graphics resolutions:
The graphic resolutions that can be displayed by the device. The graphic resolution describes the width and height dimensions of a display, such as a computer monitor, measured in pixels.
-
1920 x 1200 (WUXGA)
-
Supported video modes:
The video modes that can be displayed by the device.
-
720p, 1080p, 1080i, 576p, 480p
-
3D:
The device can be used with 3D technology.
-
No
-
Noise level (economic mode):
-
34 dB
-
AC input frequency:
-
50 - 60
-
AC input voltage:
The voltage of the AC electricity that is inputted into the product.
-
100 - 240
-
Built-in display:
A display which is part of the product, so you do not need to attach another display.
-
No
-
Market positioning:
Under which category can the device be positioned in the market, e.g. camera phone.
-
Portable
-
Zoom type:
-
Auto/Manual
-
Horizontal lens shift range:
-
-32 - 32
-
Vertical lens shift range:
-
-5 - 70
-
Smart TV:
Smart TV features access to a large number of channels that offer TV programs, movies, and music without the need to connect a TV antenna or subscribe to a cable/satellite service. Some smart TVs provide web browsing, gaming, and access to compatible media content stored on computers.
-
No
-
Native aspect ratio:
The aspect ratio is the ratio of the width of an image to its height. The native aspect ratio is the one which the projector/display is particularly designed for. Images shown in native aspect ratio will utilize the entire resolution of the display and achieve maximum brightness. Images shown in other than native aspect ratio will always have less resolution and less brightness than images shown in native aspect ratio.
-
16:9
-
Projector native resolution:
-
1080p (1920x1080)
-
Product type:
The sub-category of the product.
-
Projector module
-
Harmonized System (HS) code:
-
85286200
-
Light source type:
-
Laser
-
Service life of light source:
-
20000 h
-
Smart projector:
-
No
