SATA/SAS SSD/HDD to 3.5in SATA Hard Drive Converter StarTech.com 25SATSAS35

The StarTech.com 25SATSAS35 converter lets you install a 2.5" SATA or SAS hard drive (HDD) or solid-state drive (SSD) into a standard 3.5" SATA bay. Constructed from durable lightweight plastic with ventilation openings, the converter provides standard 3.5" mounting points on the sides and bottom and supports drives up to 15 mm height. It is compatible with SATA III controllers to enable transfer speeds up to 6 Gbps when paired with compatible hardware.

Advantages

This trayless adapter supports up to 15 mm-high 2.5" SATA or SAS drives and uses standard 3.5" mounting holes including three side mounting points for compatibility with some OEM systems. The lightweight plastic construction includes ventilation to help cooling, and the design allows the 2.5" drive to be used in 3.5" bays, drawers, caddies or enclosures. When used with SATA III drives and controllers, the converter enables transfer rates up to 6 Gbps.

Suitable for

• Installing 2.5" SATA or SAS HDDs/SSDs into desktop 3.5" drive bays
• Using 2.5" drives in 3.5" drive drawers, caddies or enclosures
• Upgrading or expanding storage in desktop systems, including some OEM models that require side mounting points

Key specifications

• Model: StarTech.com 25SATSAS35
• Compatible drive types: 2.5" SATA and SAS HDD/SSD (up to 15 mm height)
• Output form factor: 3.5" SATA
• Supported interface speed: SATA III (up to 6 Gbps with compatible controller)
• Material: Plastic
• Colour: Black
• Dimensions (manufacturer): 100 mm x 145 mm x 25 mm
• Weight: approx. 0.14–0.2 kg (product data lists 0.14 kg and summary lists 200 g)
• Certifications: RoHS

How to use

Insert the 2.5" SATA or SAS drive into the converter so that the drive’s SATA connector aligns with the converter’s internal SATA interface. Slide the drive fully into place until it is seated, then mount the assembled 3.5" form factor unit into the target 3.5" bay, drawer or enclosure using standard 3.5" mounting points. Connect power and SATA data cables to the host system. For optimal performance with SATA III drives, connect to a SATA III-capable controller.

Usage recommendations

Use this adapter in well-ventilated bays and ensure the drive is secured with the provided 3.5" mounting points; confirm controller and drive support SATA III to achieve maximum transfer speeds up to 6 Gbps.
