Weight:
Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies.
-
0.1 kg
-
Mean time between failures (MTBF):
Statistical model used to indicate product/mechanism reliability; expressed in hours and percentage of duty cycle. This number (in hours) does not indicate the mean time before failure for a single unit/mechanism.
-
31195 h
-
Full duplex:
A full-duplex system allows communication in both directions, and unlike half-duplex, allows this to happen simultaneously.
-
Yes
-
Operating relative humidity (H-H):
-
5 - 85
-
Compatible memory cards:
Types of memory cards which can be used with this product.
-
SD, MicroSD (TransFlash)
-
Chipset:
Set of electronic components in an integrated circuit that manages the data flow between the processor, memory and peripherals. It is usually found in the motherboard of a computer. Chipsets are usually designed to work with a specific family of microprocessors. Because it controls communications between the processor and external devices, the chipset plays a crucial role in determining system performance.
-
Parade - PS188, VIA - VL822, Genesys Logic - GL3231S, Realtek - RTL8153E
-
Storage temperature (T-T):
The minimum and maximum temperatures at which the product can be safely stored.
-
-10 - 70
-
Package weight:
Weight of the packaged product.
-
187 g
-
Operating temperature (T-T):
The minimum and maximum temperatures at which the product can be safely operated.
-
0 - 32
-
Ethernet LAN:
An Ethernet LAN (Local Area Network) interface is present, for a wired conection via a cable.
-
Yes
-
Height:
The measurement of the product from head to foot or from base to top.
-
14 mm
-
Output voltage:
-
5
-
LED indicators:
-
Network
-
Data transfer rate:
Rate at which data can be transferred. Usually expressed in units per second. May vary with network configurations.
-
10 Gbit/s
-
Width:
The measurement or extent of something from side to side.
-
59 mm
-
Depth:
The distance from the front to the back of something.
-
115 mm
-
Connectivity technology:
The technology that enables connectivity of the device, e.g. wired or wireless.
-
Wired
-
Product colour:
The colour e.g. red, blue, green, black, white.
-
Grey
-
USB 2.0 ports quantity:
Number of USB 2.0 ports (connecting interfaces) in the device. USB 2.0 was released in April 2000 (now called "Hi-Speed"), adding higher maximum signaling rate of 480 Mbit/s (effective throughput up to 35 MB/s or 280 Mbit/s), USB 2.0 ports are usually black.
-
1
-
Ethernet LAN (RJ-45) ports:
Number of Ethernet LAN (RJ-45) ports (connecting interfaces) in the device. Ethernet LAN (RJ-45) ports allow a computer to connect to the ethernet.
-
1
-
Headphone outputs:
Number of sockets /ports where headphones are connected.
-
0
-
Microphone in:
The socket where a microphone is connected to the device.
-
No
-
Wake-on-LAN ready:
-
Yes
-
Host interface:
Interface that enables a host controller to communicate with a driver.
-
USB 3.2 Gen 2 (3.1 Gen 2) Type-C
-
Card reader integrated:
A card reader is a device that enables reading and, in some cases, writing data to and from a memory card.
-
Yes
-
HDMI ports quantity:
The number of sockets (ports) for HDMI connections. HDMI (High-Definition Multimedia Interface) is a compact audio/video interface for transferring uncompressed video data and compressed/uncompressed digital audio data from a HDMI-compliant device ("the source device") to a compatible computer monitor, video projector, digital television, or digital audio device. HDMI is a digital replacement for existing analog video standards.
-
1
-
Ethernet LAN data rates:
The different speed levels of the Ethernet LAN connection.
-
1000, 10, 100
-
Package depth:
The distance from the front to the back of the packaging.
-
110 mm
-
Package height:
The distance from the top to the bottom of the packaging.
-
19 mm
-
Package width:
The distance from one side of the packaging to the other.
-
190 mm
-
Master (outer) case height:
-
310 mm
-
Master (outer) case width:
-
530 mm
-
Housing material:
What the casing of the product is made of.
-
Aluminium
-
HDMI version:
-
2.0
-
Maximum digital resolution:
-
3480 x 2160
-
Windows operating systems supported:
Windows vesions wich can be used with the device.
-
Windows 10 Home x64, Windows 11 Pro, Windows 11 Home, Windows 11 Enterprise x64, Windows 11 Enterprise, Windows 11, Windows 10 x64, Windows 10 Pro x64, Windows 10 Pro, Windows 10 IoT Enterprise, Windows 10 IOT Core, Windows 11 x64, Windows 10 Home, Windows 10 Enterprise x64, Windows 10 Enterprise, Windows 10 Education x64, Windows 10 Education, Windows 10, Windows 8.1
-
Mac operating systems supported:
Mac operating systems e.g. OS X can be used with the device.
-
Mac OS 26 Tahoe, Mac OS X 15.0 Sequoia, Mac OS X 14.0 Sonoma, Mac OS X 13.0 Ventura
-
Linux operating systems supported:
8 RT. Linux (9.4, 9.5), Red Hat Enterprise Linux 5.0 (supported with a pre-built package); SUSE Linux (10.3, 11.0, 11, 11.1, 11.2), Fedora (9, 9.0, 10, 10.0, 11.0, 11, 12, 12.0), Ubuntu (8.04, 8.04.1, 8.04.2, 8.10, 9.04, 9.10, 10.04), Debian (5.0, 5.0.1, 5.0.2, 5.0.3)
-
Ubuntu 24.04 LTS, Ubuntu 22.04 LTS, Ubuntu 22.04, Ubuntu 20.04 LTS
-
User guide:
-
Yes
-
USB cable length:
-
0.203 m
-
Mobile operating systems supported:
The operating systems e.g. Android, iOS, that can be used with the mobile device.
-
iPadOS, iOS
-
Number of displays supported:
The number of displays that can be used with this product.
-
1
-
HD type:
Type of supported High Definition (e.g. Full HD, 4K Ultra HD).
-
4K Ultra HD
-
UASP support:
-
Yes
-
Master (outer) case length:
-
330 mm
-
Products per master (outer) case:
-
40 pc(s)
-
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity:
-
0
-
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity:
-
2
-
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity:
Number of USB 3.1 (3.1 Gen 2) ports with Type-C connector. USB 3.1 (3.1 Gen 2) is USB interface version which supports transfer rate up to 10 Gbit/s (SuperSpeed+). USB Type-C connector has symmetrical design architecture and compatible with Thunderbolt 3 interface.
-
1
-
USB Type-C DisplayPort Alternate Mode:
-
Yes
-
USB Power Delivery (USB PD):
-
Yes
-
USB 2.0 Type-C ports quantity:
-
1
-
USB Power Delivery revision:
-
3.2
-
USB Power Delivery up to:
-
140 W
-
Compliance certificates:
Indicates which regulatory, safety, and environmental standards the product complies with, as verified by recognized authorities or certification bodies.
-
RoHS, Federal Communications Commission (FCC)
