Weight:
Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies.
-
0.07 kg
-
Operating relative humidity (H-H):
-
10 - 90
-
Storage temperature (T-T):
The minimum and maximum temperatures at which the product can be safely stored.
-
-20 - 70
-
Package weight:
Weight of the packaged product.
-
87.9 g
-
Operating temperature (T-T):
The minimum and maximum temperatures at which the product can be safely operated.
-
0 - 40
-
Cable length:
How long the cable is.
-
2 m
-
Colour depth:
-
10 bit
-
Data transfer rate:
Rate at which data can be transferred. Usually expressed in units per second. May vary with network configurations.
-
18 Gbit/s
-
Product colour:
The colour e.g. red, blue, green, black, white.
-
Black, Silver
-
Package depth:
The distance from the front to the back of the packaging.
-
60 mm
-
Package height:
The distance from the top to the bottom of the packaging.
-
158 mm
-
Package width:
The distance from one side of the packaging to the other.
-
30 mm
-
Master (outer) case height:
-
355 mm
-
Master (outer) case width:
-
345 mm
-
Supported graphics resolutions:
The graphic resolutions that can be displayed by the device. The graphic resolution describes the width and height dimensions of a display, such as a computer monitor, measured in pixels.
-
3840 x 2160, 2560 x 1440, 5120 x 2880
-
HDMI version:
-
2.0
-
HDCP:
High-bandwidth Digital Content Protection (HDCP) is a form of digital copy protection to prevent copying of digital audio and video content as it travels across connections.
-
Yes
-
Connector 1:
This is the first connector in the device.
-
HDMI Type A (Standard)
-
Connector 2:
This is the second connector in the device.
-
HDMI Type A (Standard)
-
Cable diameter:
The distance from one side of the cable to the other, with a straight line going through the middle of the cable.
-
4 mm
-
Connector contacts plating:
What the connector contacts are covered with (layer on top).
-
Gold
-
Audio Return Channel (ARC):
-
Yes
-
Connector 1 form factor:
-
Straight
-
Connector 2 form factor:
-
Straight
-
HDCP version:
-
2.2
-
Cable shielding:
The protective layer for the cable, typically made of plastic.
-
Aluminum mylar foil
-
Connector 1 gender:
The gender of the first connector of the product. Each half of a pair of mating connectors is assigned the designation male or female, the part bearing one or which fits into another being called male.
-
Male
-
Connector 2 gender:
The gender of the second connector of the product. Each half of a pair of mating connectors is assigned the designation male or female, the indented one or the one fitting around the other being called female.
-
Male
-
Quantity per pack:
-
1 pc(s)
-
Master (outer) case length:
-
330 mm
-
Products per master (outer) case:
-
100 pc(s)
-
High Dynamic Range (HDR) supported:
-
Yes
-
Supported digital audio channels (uncompressed):
-
7.1, 32
-
High Dynamic Range (HDR) technology:
-
High Dynamic Range 10 (HDR10), Dolby Vision
-
Colour sampling:
-
4:4:4
-
Cable jacket type:
-
Braided
-
Compliance certificates:
Indicates which regulatory, safety, and environmental standards the product complies with, as verified by recognized authorities or certification bodies.
-
RoHS, CE
-
HDMI cable type:
-
High Speed HDMI cable
