Weight:
Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies.
-
0.185 kg
-
Operating relative humidity (H-H):
-
10 - 90
-
Storage temperature (T-T):
The minimum and maximum temperatures at which the product can be safely stored.
-
-20 - 70
-
Package weight:
Weight of the packaged product.
-
202 g
-
Operating temperature (T-T):
The minimum and maximum temperatures at which the product can be safely operated.
-
0 - 40
-
Cable length:
How long the cable is.
-
2 m
-
Cable type:
Type of cable e.g. electicity cable, optical cable.
-
Round cable
-
Data transfer rate:
Rate at which data can be transferred. Usually expressed in units per second. May vary with network configurations.
-
48 Gbit/s
-
Product colour:
The colour e.g. red, blue, green, black, white.
-
Black
-
Package depth:
The distance from the front to the back of the packaging.
-
110 mm
-
Package height:
The distance from the top to the bottom of the packaging.
-
23 mm
-
Package width:
The distance from one side of the packaging to the other.
-
190 mm
-
Master (outer) case height:
-
265 mm
-
Master (outer) case width:
-
410 mm
-
Supported graphics resolutions:
The graphic resolutions that can be displayed by the device. The graphic resolution describes the width and height dimensions of a display, such as a computer monitor, measured in pixels.
-
10240 x 4320, 7680 x 4320, 3840 x 2160, 2560 x 1440
-
HDMI version:
-
2.1
-
HDCP:
High-bandwidth Digital Content Protection (HDCP) is a form of digital copy protection to prevent copying of digital audio and video content as it travels across connections.
-
Yes
-
Connector 1:
This is the first connector in the device.
-
HDMI Type A (Standard)
-
Connector 2:
This is the second connector in the device.
-
HDMI Type A (Standard)
-
Cable diameter:
The distance from one side of the cable to the other, with a straight line going through the middle of the cable.
-
4 mm
-
Connector contacts plating:
What the connector contacts are covered with (layer on top).
-
Gold
-
Maximum refresh rate:
-
240 Hz
-
Dolby technologies:
-
Dolby TrueHD, Dolby Atmos, DTS:X
-
Connector 1 form factor:
-
Straight
-
Connector 2 form factor:
-
Straight
-
HDCP version:
-
2.3
-
AWG wire size:
-
34
-
Cable shielding:
The protective layer for the cable, typically made of plastic.
-
Aluminum mylar foil
-
Connector 1 gender:
The gender of the first connector of the product. Each half of a pair of mating connectors is assigned the designation male or female, the part bearing one or which fits into another being called male.
-
Male
-
Connector 2 gender:
The gender of the second connector of the product. Each half of a pair of mating connectors is assigned the designation male or female, the indented one or the one fitting around the other being called female.
-
Male
-
Cable jacket material:
-
Thermoplastic elastomer (TPE)
-
Quantity per pack:
-
1 pc(s)
-
Master (outer) case length:
-
275 mm
-
Products per master (outer) case:
-
40 pc(s)
-
High Dynamic Range (HDR) supported:
-
Yes
-
Enhanced Audio Return Channel (eARC):
-
Yes
-
Supported digital audio channels (uncompressed):
-
32, 7.1
-
High Dynamic Range (HDR) technology:
-
High Dynamic Range 10+ (HDR10 Plus), Dolby Vision
-
Compliance certificates:
Indicates which regulatory, safety, and environmental standards the product complies with, as verified by recognized authorities or certification bodies.
-
RoHS, CE
-
HDMI cable type:
-
Ultra High Speed HDMI cable
