Operating relative humidity (H-H):
-
10 - 90
-
Storage temperature (T-T):
The minimum and maximum temperatures at which the product can be safely stored.
-
-20 - 70
-
Package weight:
Weight of the packaged product.
-
125 g
-
Operating temperature (T-T):
The minimum and maximum temperatures at which the product can be safely operated.
-
0 - 40
-
Cable length:
How long the cable is.
-
2 m
-
Cable type:
Type of cable e.g. electicity cable, optical cable.
-
Round cable
-
Colour depth:
-
10 bit
-
Data transfer rate:
Rate at which data can be transferred. Usually expressed in units per second. May vary with network configurations.
-
18 Gbit/s
-
Product colour:
The colour e.g. red, blue, green, black, white.
-
Black
-
Package depth:
The distance from the front to the back of the packaging.
-
110 mm
-
Package height:
The distance from the top to the bottom of the packaging.
-
23 mm
-
Package width:
The distance from one side of the packaging to the other.
-
190 mm
-
Master (outer) case height:
-
250 mm
-
Master (outer) case width:
-
400 mm
-
Supported graphics resolutions:
The graphic resolutions that can be displayed by the device. The graphic resolution describes the width and height dimensions of a display, such as a computer monitor, measured in pixels.
-
5120 x 2880, 3840 x 2160, 2560 x 1400, 1920 x 1080 (HD 1080)
-
HDMI version:
-
2.0
-
HDCP:
High-bandwidth Digital Content Protection (HDCP) is a form of digital copy protection to prevent copying of digital audio and video content as it travels across connections.
-
Yes
-
Connector 1:
This is the first connector in the device.
-
HDMI Type A (Standard)
-
Connector 2:
This is the second connector in the device.
-
HDMI Type A (Standard)
-
Connector contacts plating:
What the connector contacts are covered with (layer on top).
-
Gold
-
Dolby technologies:
-
Dolby TrueHD
-
Connector 1 form factor:
-
Straight
-
Connector 2 form factor:
-
Straight
-
HDCP version:
-
2.2
-
Cable shielding:
The protective layer for the cable, typically made of plastic.
-
Aluminum mylar foil
-
Connector 1 gender:
The gender of the first connector of the product. Each half of a pair of mating connectors is assigned the designation male or female, the part bearing one or which fits into another being called male.
-
Male
-
Connector 2 gender:
The gender of the second connector of the product. Each half of a pair of mating connectors is assigned the designation male or female, the indented one or the one fitting around the other being called female.
-
Female
-
Cable jacket material:
-
Thermoplastic elastomer (TPE)
-
Quantity per pack:
-
1 pc(s)
-
Master (outer) case length:
-
350 mm
-
Products per master (outer) case:
-
60 pc(s)
-
High Dynamic Range (HDR) supported:
-
Yes
-
Supported digital audio channels (uncompressed):
-
32, 7.1
-
High Dynamic Range (HDR) technology:
-
High Dynamic Range 10 (HDR10), Dolby Vision
-
Colour sampling:
-
4:4:4
-
Compliance certificates:
Indicates which regulatory, safety, and environmental standards the product complies with, as verified by recognized authorities or certification bodies.
-
RoHS
-
HDMI cable type:
-
High Speed HDMI cable
