StarTech MSAT2SAT3 SATA Drive to mSATA Host Adapter with 6 Gbit/s Data Transfer Rate

The StarTech MSAT2SAT3 SATA Drive to mSATA Host Adapter with 6 Gbit/s Data Transfer Rate is designed to bridge the gap between different storage form factors. This adapter features an mSATA host interface and a SATA output interface, allowing users to connect standard 2.5-inch or 3.5-inch SATA hard drives, solid-state drives, or optical disk drives to an available mSATA slot. Built to facilitate efficient hardware integration, this device supports high-speed data transfers up to 6 Gbit/s and remains fully backward compatible with older SATA revisions.

Advantages

Using this adapter provides a practical method for expanding storage capacity in systems constrained by available drive bays or interface types. By converting an internal mSATA port into a standard SATA connection, users can easily deploy higher-capacity storage media or optical drives without replacing existing motherboards or controllers. The hardware-based conversion requires no software installation or specialized drivers, functioning across various operating systems for straightforward deployment.

Suitable for

• Connecting 2.5-inch and 3.5-inch SATA hard drives or SSDs to an mSATA host port
• Adding optical disk drives such as Blu-ray or DVD players to systems with mSATA slots
• Upgrading internal system storage capacity in desktop computers and custom enclosures
• Data recovery operations requiring temporary access to standard SATA drives via an mSATA interface

When it may not be suitable

This adapter is not designed for systems lacking an internal mSATA slot or for users attempting to connect mSATA drives to a standard SATA motherboard port, as the physical interface direction is reversed. Additionally, connecting 3.5-inch SATA devices requires an independent power source, as the mSATA port alone cannot supply sufficient power for larger mechanical drives.

Key specifications

• Host interface: mSATA
• Output interface: SATA
• Maximum data transfer rate: 6 Gbit/s
• Color: Green
• Physical dimensions: Width 30 mm, Depth 51 mm, Height 8 mm
• Operating temperature range: 5 to 50 °C
• Storage temperature range: -25 to 70 °C

How to use

Installation involves securing the adapter directly onto the motherboard or compatible enclosure utilizing the provided mounting kit. Connect the standard SATA drive to the output interface of the adapter while ensuring the mSATA connector is properly seated in the host port. For 3.5-inch devices, connect an auxiliary power supply to the drive. Power on the system, and the connected hardware will be recognized by the operating system automatically without manual driver configuration.

What to consider before purchase

• Verify the presence of an available internal mSATA slot on your motherboard or host device
• Confirm whether your target storage drive requires additional power cables, particularly for 3.5-inch mechanical hard drives or optical units
• Check physical clearance within your computer case or enclosure to ensure the combined adapter and drive assembly fits securely

Usage recommendations: Handle the adapter by its edges to prevent electrostatic discharge damage to sensitive electronic components. Ensure all cables are securely fastened and auxiliary power is correctly supplied to larger mechanical drives before powering on the system.
