Short description

The StarTech.com 2 Port PCI Express SATA 6 Gbps eSATA Controller Card offers dual ports for internal and external connections. It features a PCIe host interface and supports SATA III with a chipset of ASMedia ASM1061. This card is compatible with various Windows operating systems including Windows 10 and Windows Server editions. With dimensions of 92 mm width, 121 mm depth, and 20 mm height, it is compact yet powerful, providing reliable data transfer rates up to 6 Gbps.

Available at price 50.99 €: 15 pcs.

Total available for order: 45 pcs.

Warranty: 2 Years

SKU: 434471

Manufacturer: StarTech

Learn more

Deliver the order:

{{ userCountryName }}

to the Customer Service Center at Kengaraga 2b, Riga

02.07.2026 {{selectedOffer.officeDeliveryString}}

free

All delivery methods Hide details

Customer service center

2b. Kengaraga str., Riga, Latvia, LV-1063

02.07.2026 {{selectedOffer.officeDeliveryString}}

free

Courier Delivery Please note that in case of a large parcel additional delivery costs may apply!

07.07.2026 {{selectedOffer.courierDeliveryString}}

From 4.99 € (Weight: 0.15 kg)

Parcel couriers

Latvijas Pasts pakomāts / Unisend LV / DPD Paku skapis / Omniva LV / Venipak Pickup LV / Venipak Locker LV / Latvijas Pasts nodaļa

07.07.2026 {{selectedOffer.parcelStationDeliveryString}}

From 1.99 €

More about delivery methods

Payment Methods:

Cash payment, Bank transfer, Bank cards on-line, Apple Pay, Google Pay

Available for private customers at price 54.49 €: 15 pcs.

More about payment methods

You saving {{productBundleYouSave | formatAmount}}

Product information

Description

The StarTech.com PEXESAT322I is a PCI Express (x1) SATA III controller card that adds two SATA 6 Gbps ports to a desktop computer. The card can be configured via onboard jumpers to provide two internal ports, two external eSATA ports, or one internal and one external port. It uses the ASMedia ASM1061 chipset and supports the SATA revision 3.0 specification for data transfer rates up to 6 Gbps, allowing use with high-performance hard drives, SSDs and SATA optical drives. The card is compact and compatible with common Windows operating systems, and includes a two-year manufacturer warranty and free lifetime technical support.

Advantages

The PEXESAT322I offers flexible port configuration through onboard jumper selection, enabling internal, external or mixed port setups. Each port supports Port Multiplier (PM) to connect multiple SATA drives over a single cable when needed, reducing cabling while expanding device connectivity. Compliance with SATA 3.0 ensures up to 6 Gbps bandwidth for modern HDDs and SSDs, and the PCIe x1 interface provides easy installation into standard desktop systems.

Suitable for

Adding internal SATA ports for additional HDDs or SSDs
Providing eSATA external connections for fast external storage
Connecting multiple drives via Port Multiplier for RAID arrays or expanded storage
Upgrading older systems to support SATA III speeds

Key specifications

Model: StarTech.com PEXESAT322I
Interface: PCI Express (x1)
Ports: 2 configurable SATA III ports (internal/external or mixed)
Data rate: SATA revision 3.0, up to 6 Gbps
Chipset: ASMedia ASM1061
Features: Port Multiplier (PM) support
Compatibility: Windows operating systems (including Windows 10 and Server editions)
Dimensions: 92 mm (W) x 121 mm (D) x 20 mm (H)
Weight: 0.048 kg
Warranty: 2-year manufacturer warranty; free lifetime technical support

How to use

Power off the computer and insert the PEXESAT322I into an available PCI Express x1 slot on the motherboard. Configure the onboard jumpers to select internal, external or mixed port orientation before powering on. Secure any internal SATA drives to the chassis and connect them to the internal SATA ports, or connect external eSATA devices to the external ports using appropriate cables. Install drivers if required by your operating system—Windows often provides native support but check StarTech.com for the latest drivers or firmware. After installation, verify that the new drives are detected in BIOS/UEFI and the operating system’s disk management utility.

Usage recommendations

For reliable performance, use high-quality SATA III cables and ensure the motherboard BIOS and operating system are updated. When using Port Multiplier setups, confirm that your enclosure or connected device supports PM, and consult drive manufacturer guidance for RAID or multi-drive configurations.

Specifications

Host interface:: PCIe
Weight:: 0.048 kg
Internal:: Yes
Output interface:: SATA

All features

Operational conditions

Operating relative humidity (H-H):: 5 - 85
Storage temperature (T-T):: -20 - 60
Operating temperature (T-T):: 0 - 50

Technical details

Compliance certificates:: RoHS

Ports & interfaces

Host interface:: PCIe
eSATA ports quantity:: 2
Output interface:: SATA
Internal SATA ports quantity:: 2
SATA revision:: 3.0
Port multiplier:: Yes

Other features

Quantity:: 1
Manual:: Yes
Drivers included:: Yes

Weight & dimensions

Weight:: 0.048 kg
Package weight:: 152 g
Height:: 20 mm
Width:: 92 mm
Depth:: 121 mm

System requirements

Windows operating systems supported:: Windows 8.1 Enterprise, Windows 7 Ultimate, Windows 8.1 Enterprise x64, Windows 8.1, Windows 8 x64, Windows 8 Pro x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64, Windows 8 Enterprise x64, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Pro, Windows 7 Home Basic x64
Server operating systems supported:: Windows Server 2003, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019

Design

Internal:: Yes

Performance

Certification:: CE, FCC, REACH
Chipset:: ASMedia - ASM1061
Logical block addressing (LBA) support:: 48 bit

Logistics data

Master (outer) case height:: 360 mm
Master (outer) case width:: 307 mm
Master (outer) case length:: 586 mm
Products per master (outer) case:: 80 pc(s)
Harmonized System (HS) code:: 84733020

Features

Native Command Queuing (NCQ):: Yes

Packaging data

Cables included:: SATA
Package depth:: 144 mm
Package height:: 30 mm
Package width:: 173 mm
Mounting brackets included:: Yes
