Short description

The StarTech.com 2-Port USB PCIe Card offers two USB 3.1/3.2 Gen 2 Type-A ports with a maximum data transfer rate of 10 Gbps per port. Compatible with Windows and Linux operating systems, this full/low profile expansion card is ideal for enhancing your system's connectivity. Dimensions: 120mm x 110mm x 19mm.

Available at price 44.49 €: 2 pcs.

Total available for order: 40 pcs.

Warranty: 2 Years

SKU: 4059568

Manufacturer: StarTech

Learn more

Deliver the order:

{{ userCountryName }}

to the Customer Service Center at Kengaraga 2b, Riga

02.07.2026 {{selectedOffer.officeDeliveryString}}

free

All delivery methods Hide details

Customer service center

2b. Kengaraga str., Riga, Latvia, LV-1063

02.07.2026 {{selectedOffer.officeDeliveryString}}

free

Courier Delivery Please note that in case of a large parcel additional delivery costs may apply!

07.07.2026 {{selectedOffer.courierDeliveryString}}

From 4.99 € (Weight: 0.14 kg)

Parcel couriers

Latvijas Pasts pakomāts / Unisend LV / DPD Paku skapis / Omniva LV / Venipak Pickup LV / Venipak Locker LV / Latvijas Pasts nodaļa

07.07.2026 {{selectedOffer.parcelStationDeliveryString}}

From 1.99 €

More about delivery methods

Payment Methods:

Cash payment, Bank transfer, Bank cards on-line, Apple Pay, Google Pay

Available for private customers at price 45.49 €: 20 pcs.

More about payment methods

You saving {{productBundleYouSave | formatAmount}}

Product information

Description

The StarTech.com Expansion Card 2-Port USB PCIe (PEXUSB312A3) installs into an available PCIe x4 slot and adds two USB 3.2 Gen 2 (10 Gbps) Type-A ports to a desktop computer. The black, low-profile/full-profile compatible card uses an ASMedia ASM3142 controller and supports PCIe 3.0 x2 lanes, enabling high-speed connections for external drives, SSDs and other USB devices.

Advantages

This PCIe USB 3.2 Gen 2 controller provides two SuperSpeed USB-A ports with up to 10 Gbps per port and backward compatibility with USB 3.2 Gen 1 (5 Gbps) and USB 2.0. Each port supplies up to 4.5W (5V/0.9A) for powering and syncing mobile devices. The ASM3142 controller supports UASP and Multiple INs to reduce bandwidth loss when multiple devices are connected. The card includes full-profile and low-profile brackets and is supported on Windows, Linux and macOS, with automatic driver installation on Windows 8 and later.

Suitable for

Connecting external hard drives and solid-state drives
Transferring large files at high speed (backup, media libraries)
Adding high-speed USB-A ports to desktop PCs without native USB 3.2 Gen 2
Powering and syncing mobile devices

Key specifications

Model: PEXUSB312A3
Interface: PCIe 3.0 (x2 lanes), backward compatible with PCIe 2.0
Output: 2 × USB 3.2 Gen 2 Type-A ports (10 Gbps per port)
Controller: ASMedia ASM3142
Power per port: up to 4.5W (5V/0.9A)
Compatibility: Windows, Linux, macOS; drivers auto-install on Windows 8+
Profile: Includes full-profile and low-profile brackets
Colour: Black
Dimensions (manufacturer data): 120 mm × 110 mm × 19 mm
Weight: 0.078 kg

How to use

Power off the computer, open the case and install the card into an available PCIe x4 (or larger) slot. Secure the bracket and choose the appropriate full- or low-profile bracket for your case. Reassemble the computer and power it on; on Windows 8 or later the drivers install automatically. Connect USB devices to the Type-A ports to begin data transfer. For optimal performance use USB 3.2 Gen 2 compatible cables and devices and connect directly to the card rather than through unpowered hubs when possible.

Usage recommendations

To maximize throughput, use dedicated high-quality USB 3.2 Gen 2 cables and connect high-performance storage devices directly to the card. When connecting multiple high-bandwidth devices, verify hub support for Multiple INs to avoid bandwidth limitations.

Specifications

Host interface:: PCIe
Weight:: 0.078 kg
Internal:: Yes
Output interface:: USB 3.2 Gen 2 (3.1 Gen 2)
Product colour:: Black

All features

Operational conditions

Operating relative humidity (H-H):: 20 - 80
Storage temperature (T-T):: -20 - 60
Operating temperature (T-T):: 5 - 50

Ports & interfaces

Host interface:: PCIe
Output interface:: USB 3.2 Gen 2 (3.1 Gen 2)
Internal SATA ports quantity:: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity:: 2
SATA power connector type:: SATA 15-pin
Expansion card standard:: PCIe 3.0
Expansion card form factor:: Full-height / Low-profile

Weight & dimensions

Weight:: 0.078 kg
Package weight:: 142 g
Height:: 19 mm
Width:: 120 mm
Depth:: 110 mm

System requirements

Windows operating systems supported:: Windows 7 Ultimate x64, Windows 7 Enterprise x64, Windows 7 x64, Windows 7 Ultimate, Windows 7 Starter x64, Windows 7 Starter, Windows 7 Professional x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows 7 Home Premium x64, Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro x64, Windows 10 x64, Windows 7, Windows 7 Enterprise, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Professional, Windows 10 Pro
Mac operating systems supported:: Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 11.0 Big Sur, Mac OS X 13.0 Ventura
Linux operating systems supported:: Y
Server operating systems supported:: Windows Server 2012 R2, Windows Server 2016, Windows Server 2019

Design

Internal:: Yes
Product colour:: Black

Logistics data

Master (outer) case height:: 370 mm
Master (outer) case width:: 590 mm
Master (outer) case length:: 315 mm
Products per master (outer) case:: 80 pc(s)
Harmonized System (HS) code:: 84733020

Packaging data

Package depth:: 145 mm
Package height:: 30 mm
Package width:: 215 mm
Quick installation guide:: Yes
Mounting brackets included:: Yes

Features

Data transfer rate (max):: 10 Gbit/s
