TDM Brass 1635 Pressed Adaptor 26mm x 3/4" V-profile

The TDM Brass 1635 pressed adaptor is a professional-grade plumbing component engineered for creating secure and durable connections between pipes and threaded fittings. Designed with a 26mm diameter and a 3/4 inch thread, this adaptor is specifically optimized for V-profile pressing systems, ensuring high mechanical strength and long-term reliability in various fluid transport applications.

Advantages

This adaptor stands out due to its robust brass construction, which offers excellent resistance to corrosion and mechanical stress. The precision-engineered V-profile ensures a consistent and uniform compression during the pressing process, which is critical for maintaining a leak-proof seal under varying pressure and temperature conditions. Its design facilitates quick and efficient installation, reducing labor time while maintaining high safety standards in plumbing infrastructure.

Suitable for

• Residential heating system installations
• Potable water supply networks
• Connecting multi-layer pipes to threaded valves or manifolds
• Professional plumbing and HVAC maintenance

When it may not be suitable

This component is not compatible with piping systems that require different pressing profiles, such as TH or U profiles. It is also not intended for use in high-pressure industrial steam lines or systems involving highly corrosive chemicals that could degrade the brass material.

Key specifications

• Material: High-quality brass
• Connection type: Pressed fitting to threaded male connection
• Pipe diameter: 26mm
• Thread size: 3/4 inch
• Profile compatibility: V-profile

How to use

To install the TDM Brass 1635 adaptor, ensure the pipe end is cut square and properly deburred to prevent damage to the internal O-ring. Insert the pipe fully into the fitting until it reaches the stop point. Use a compatible pressing tool equipped with the correct V-profile jaws to compress the fitting onto the pipe. Once the pressing cycle is complete, verify the connection for proper alignment and ensure the threaded side is tightened securely using appropriate tools and sealing materials like PTFE tape or liquid thread sealant.

What to consider before purchase

• Verify that your pressing tool is compatible with the V-profile standard.
• Ensure the pipe diameter matches the 26mm specification exactly.
• Check the thread type of your existing equipment to ensure a 3/4 inch male connection is required.
• Confirm the operating temperature and pressure limits of your system align with the fitting specifications.

Usage recommendations

Always use professional-grade pressing equipment and ensure that the jaws are clean and free of debris before starting the installation to guarantee a perfect seal.
