TDM Brass Pressed Elbow Art 1675 26mm x 3/4" Internal Thread

The TDM Brass Pressed Elbow Art 1675 is a professional-grade plumbing fitting engineered for creating secure and durable 90-degree transitions in piping systems. This component features a 26mm press connection on one end and a 3/4" internal thread on the other, facilitating a seamless connection between press-fit pipes and threaded components. Crafted from high-quality brass, this elbow is designed to withstand the rigors of water supply and heating installations, ensuring long-term structural integrity and resistance to environmental stress.

Advantages

The primary benefit of this brass pressed elbow is its ability to provide a permanent, leak-proof connection that maintains system reliability over time. The use of high-quality brass material offers excellent corrosion resistance, making it an ideal choice for both potable water and heating applications. Its precise design ensures compatibility with standard press-fit tools, allowing for efficient installation that reduces labor time while maintaining high safety standards in plumbing infrastructure.

Suitable for

• Residential water supply systems
• Central heating installations
• Connecting press-fit piping to threaded valves or equipment
• Professional plumbing and HVAC maintenance

This fitting may not be suitable for high-pressure industrial steam lines or systems involving highly corrosive chemicals that are incompatible with brass alloys. It is also not intended for use in applications requiring flexible joints or movement, as the press-fit connection is designed to be rigid and permanent.

Key specifications

• Material: Brass
• Connection type: 26mm press-fit to 3/4" internal thread
• Angle: 90 degrees
• Application: Water supply and heating systems

To install the TDM Brass Pressed Elbow, ensure the pipe end is clean, deburred, and properly calibrated. Insert the pipe into the press end of the fitting until it reaches the stop point. Use a compatible press tool with the correct profile to compress the fitting onto the pipe, creating a secure seal. For the threaded side, apply appropriate thread sealant or PTFE tape to the male component before screwing it into the 3/4" internal thread to ensure a watertight connection.

What to consider before purchase

• Verify the outer diameter of your piping matches the 26mm press connection requirement.
• Ensure the threaded component you are connecting has a standard 3/4" male thread.
• Confirm that your press tool is compatible with the fitting profile.
• Check local plumbing codes for material compatibility in your specific region.

Always perform a pressure test on the system after installation to verify that all connections are secure and leak-free before concealing the pipes behind walls or under floors.
