TDM Brass Elbow 1" Female-Male Threaded Fitting

The TDM Brass 1" elbow is a professional-grade threaded plumbing fitting engineered to facilitate a precise 90-degree change in piping direction. Constructed from high-quality brass, this component is designed for durability and long-term performance in various fluid transport systems. It features a female-to-male connection configuration, allowing for seamless integration into existing water supply or heating networks where a secure, leak-proof joint is required.

Advantages

This brass elbow offers exceptional resistance to corrosion and mechanical wear, ensuring structural integrity even under demanding conditions. The precision-machined threads provide a tight and reliable seal, which minimizes the risk of leaks and maintenance requirements. Its robust material composition makes it suitable for both residential and industrial applications, providing a stable connection that withstands temperature fluctuations and pressure changes over time.

Suitable for

• Water supply systems
• Heating installations
• Industrial piping networks
• Directional changes in plumbing layouts

When it may not be suitable

This fitting is not intended for use in systems involving highly corrosive chemicals that may degrade brass over time. It is also not suitable for applications requiring non-metallic materials or specific food-grade certifications not covered by standard brass plumbing components.

Key specifications

• Material: Brass
• Connection type: Female-Male (V/I)
• Angle: 90 degrees
• Operating temperature range: -20°C to 120°C
• Connection count: 2

How to use

To install the TDM Brass 1" elbow, ensure that the piping system is depressurized and drained. Clean the threads of both the pipe and the fitting to remove any debris. Apply an appropriate thread sealant, such as PTFE tape or a liquid pipe sealant, to the male threads to ensure a watertight connection. Thread the male end of the fitting into the female component and the pipe into the female end of the elbow, tightening them securely with a suitable wrench. Avoid overtightening to prevent damage to the threads.

What to consider before purchase

• Verify that the 1-inch pipe diameter matches your existing system requirements.
• Ensure the female-to-male configuration aligns with your specific piping layout.
• Check that the operating temperature and pressure of your system fall within the specified limits.

Usage recommendations

For optimal performance, always use compatible tools during installation to avoid marring the brass surface. Regularly inspect the connection for signs of moisture or leaks after the initial installation and during routine maintenance checks.
