Door lock Tedee modular cylinder 30-61 mm / 37-68 mm OWKSFS06168.9005LP

The Tedee modular cylinder 30-61 mm / 37-68 mm is a configurable door lock cylinder designed to provide secure mechanical operation and flexible fit for a range of door thicknesses. Engineered for compatibility with Tedee modular systems, this cylinder supports retrofit projects and new installations where adjustable inner and outer lengths are required. The modular design enables straightforward replacement of existing cylinders while keeping integration with smart lock components possible.

Advantages

The modular construction allows precise length adjustment to match asymmetric doors or frames, reducing the need for additional machining. Made to meet common mechanical security expectations, the cylinder offers a reliable turning action and secure engagement with standard lock mechanisms. Compatibility with Tedee components ensures the cylinder can be used in systems that combine mechanical and electronic locking elements. Installation and future replacement are simplified by the adaptable length ranges on both inner and outer sides.

Suitable for

• Retrofit of existing doors requiring varied inner and outer cylinder lengths
• New door installations where asymmetric thickness or fittings are present
• Integration with Tedee modular locking systems and smart lock upgrades
• Residential and light commercial doors with standard European cylinder profiles

Key specifications

• Adjustable inner length range: 30–61 mm
• Adjustable outer length range: 37–68 mm
• Modular cylinder design for length customization
• Compatible with standard cylinder-mounted lock mechanisms
• Intended for retrofit and new installations with varying door thicknesses

How to use

Select the cylinder orientation and extension segments to match the measured inner and outer door thicknesses. Follow the door preparation instructions for removing the existing cylinder: unlock and retract any latch, remove the fixing screw, and gently slide the old cylinder out. Fit the modular cylinder by inserting it into the lock body, ensuring the cam aligns with the lock mechanism, then secure with the fixing screw and test the turning action. When integrating with Tedee smart components, follow the manufacturer’s mechanical and electronic integration steps to preserve functionality and alignment.

Usage recommendations

Verify door and hardware measurements before purchase to ensure the inner and outer adjustable ranges cover the required dimensions. Use recommended torque values for fixing screws and test locking action several times after installation. For installations involving smart components, consult Tedee integration documentation to confirm mechanical compatibility and mounting clearances.
