header-product Satellite multiswitch Televes 714201 9 inputs 17 outputs
277.49 €

Satellite multiswitch Televes 714201 9 inputs 17 outputs

Satellite multiswitch Televes 714201 Photo 1
Satellite multiswitch Televes 714201 Photo 2
Satellite multiswitch Televes 714201 Photo 1
Satellite multiswitch Televes 714201 Photo 2
Keep track of price changes You keep track of price changes
Watch the price drop

Leave your address - as soon as the price of the product goes down, you'll know about it right away

You keep track of price changes

Satellite multiswitch Televes 714201 9 inputs 17 outputs

{{email}}
You keep track of price changes

Satellite multiswitch Televes 714201 9 inputs 17 outputs

{{email}}
{{selectedOffer && selectedOffer.price | formatAmount}}

Short description

The Televes 714201 satellite multiswitch features 9 inputs and 17 outputs, supporting input frequencies from 950 to 2400 MHz. It operates on 12 V with a voltage range of 90 to 112 dBμV and has a current consumption of 125 mA. Compact dimensions of 208 mm width, 30 mm depth, and 120 mm height make it suitable for various installations, ensuring reliable signal distribution for multiple satellite connections.
Available for order: 7 pcs.
Warranty: 2 Years
SKU: 1100465
Manufacturer: Televes
free shipment

Cheapest delivery:

Venipak Pickup LV, Venipak Locker LV

Pick-up points

Venipak Pickup LV

Venipak Locker LV

Cost

1.89 €

Deliver

{{selectedOffer.parcelStationDeliveryString}}

Customer service center
2b. Kengaraga str., Riga, Latvia, LV-1063
03.08.2026 {{selectedOffer.officeDeliveryString}}
free
Courier Delivery Please note that in case of a large parcel additional delivery costs may apply!
06.08.2026 {{selectedOffer.courierDeliveryString}}
From 4.99 € (Weight: 1.00 kg)
Parcel couriers
Venipak Pickup LV / Venipak Locker LV / Latvijas Pasts pakomāts / Unisend LV / DPD Paku skapis / Omniva LV / Latvijas Pasts nodaļa
06.08.2026 {{selectedOffer.parcelStationDeliveryString}}
From 1.89 €
payment
Payment Methods:
Bank transfer
Together cheaper
{{product.price | formatAmount}}
{{product.title}}
{{productBundle.reference.specialPrice | formatAmount}}
{{productBundle.title}}
{{productBundlePreviousPrice | formatAmount}}
{{productBundleSpecialPrice | formatAmount}}

You saving {{productBundleYouSave | formatAmount}}

Product information

Description

The Televes 714201 satellite multiswitch supplies signal distribution from two satellites and a terrestrial antenna to multiple receivers. It features nine inputs (one terrestrial and eight satellite polarities) and seventeen outputs, supporting input frequencies from 950 to 2400 MHz. The unit can be installed as a terminal in a star topology or used in cascade with a simple switch, and it is designed and manufactured in Europe.

Advantages

This multiswitch is quad-compatible and includes a 22 kHz generator for optimized operation with Quad LNBs. Each group of eight user outputs has a 10 dB Low Gain/High Gain switch for attenuating satellite input signals as needed. The device is compatible with return-channel applications and offers compact dimensions (208 × 30 × 120 mm) with low current consumption (125 mA) at 12 V operation.

Suitable for

  • Distributing satellite and terrestrial TV signals to multiple receivers in homes or small buildings
  • Installations using Quad LNBs and multi-satellite configurations
  • Setups requiring cascade connection or star-topology terminal distribution

Key specifications

  • Model: Televes 714201
  • Inputs: 9 (1 terrestrial + 8 satellite polarities)
  • Outputs: 17
  • Frequency range: 950–2400 MHz
  • Supply voltage: 12 V
  • Signal level range: 90–112 dBμV
  • Current consumption: 125 mA
  • Dimensions (W×D×H): 208 × 30 × 120 mm
  • EAN: 8424450187418

How to use

Connect the terrestrial antenna to the terrestrial input and the two satellite LNBs to the satellite inputs (all four polarities per satellite). Mount the multiswitch in a suitable cabinet or on a wall, provide a 12 V power supply, and route coaxial cables from the user outputs to each receiver. Use the 10 dB LG/HG switch for each eight-user group to adjust satellite signal attenuation when necessary. For cascade installations, use a compatible switch to link units as required.

Usage recommendations

For stable reception, verify cable quality and connector integrity, set the LG/HG switches according to signal levels measured at receivers, and ensure the Quad LNB is compatible with the 22 kHz generator. Follow local grounding and installation standards during setup.

Specifications

Weight:
0.56 kg
All features
Input voltage:
12
Number of inputs:
9 inputs
Number of outputs:
17 outputs
Input voltage range:
90 - 112
Current consumption:
125 mA
Through loss (terrestrial):
2 dB
Through loss (satellite):
5 dB
Input frequency range (terrestrial):
88 - 862
Input frequency range (satellite):
950 - 2400

Technical details

International Protection (IP) code: Device protection rating against dust and water according to the international IP standard.
IP20

Weight & dimensions

Weight:
0.56 kg
Height:
120 mm
Width:
208 mm
Depth:
30 mm

Operational conditions

Operating temperature (T-T):
-5 - 45

Packaging data

Package weight:
626 g
