Tip fork M4 crimped copper 4.32 mm – EB448088998

Crimped copper tip fork for M4 connections with a 4.32 mm width, model EB448088998, designed to provide a reliable electrical termination on M4 screw terminals. The fork-style copper contact is formed and crimped to the conductor to deliver consistent mechanical retention and low-resistance electrical contact in control panels, wiring harnesses, and industrial or automotive assemblies where secure M4 connections are required.

Advantages

The crimped copper fork features a precise 4.32 mm fork width matched to M4 screw hardware and a formed body that promotes consistent contact pressure and minimized contact resistance. Being a copper contact, it offers good conductivity and corrosion resistance when used with appropriate plating or protective treatments. The crimp-style termination enables repeatable mechanical retention and ease of installation with common crimping tools, reducing the risk of loose connections in vibration-prone environments.

Suitable for

• Electrical control panels and distribution blocks using M4 screw terminals
• Wiring harnesses in industrial machinery and equipment
• Automotive and vehicle electrical assemblies requiring secure M4 connections
• Maintenance and repair tasks where replacement fork terminals are needed

Key specifications

• Material: copper contact designed for electrical conductivity
• Fork width: 4.32 mm suitable for M4 screw terminals
• Termination style: crimped fork for conductor attachment
• Intended use: screw-terminal electrical connections with M4 hardware

How to use

Strip the conductor to the recommended insulation strip length for the chosen crimp terminal, insert the bare conductor fully into the barrel of the crimped fork, and apply a suitable crimping tool sized for the terminal and conductor cross-section. After crimping, inspect the crimp for proper compression and that no strands are splayed. Fit the fork under the M4 screw or nut, ensuring the screw makes direct contact with the fork tines, and tighten to the appropriate torque specified for the screw terminal to secure the electrical and mechanical connection.

Рекомендации по использованию

Use compatible wire cross-sections and a matched crimping die; verify torque settings for the M4 terminal and apply corrosion protection or plating considerations as required by the installation environment.
