Fusion saddle Unidelta Mufa elektrooporowa PE100 SDR11 63mm (671006) — electrofusion saddle for PE pipe

Electrofusion saddle Unidelta Mufa elektrooporowa PE100 SDR11 63mm is an electrofusion fitting designed to create a reliable branch connection on PE100 SDR11 pipes with a 63 mm nominal diameter. The saddle incorporates embedded heating elements that, when connected to a compatible electrofusion control unit, produce a homogeneous fusion between the saddle and the host pipe. It is intended for permanent, pressure-tight connections in gas and water distribution systems, service laterals and localized repair works on polyethylene pipelines.

Advantages

The electrofusion saddle provides a controlled fusion process that ensures consistent joints with reduced dependence on operator technique. Integrated heating coils deliver uniform heat distribution to the PE material, promoting a homogeneous molecular bond between saddle and pipe. The design minimizes excavation and mechanical stress at the connection point, and the saddle form offers a compact branching solution suitable for confined installation spaces.

Suitable for

• Branching service connections for water and gas distribution
• On-site repair of damaged sections or fittings on PE pipelines
• Making permanent, pressure-tight lateral connections in buried installations
• Situations requiring compact, low-profile electrofusion branches

Key specifications

• Material: PE100 compatible electrofusion-grade polyethylene
• Pipe standard compatibility: SDR11
• Nominal pipe diameter: 63 mm
• Joint method: electrofusion with integrated heating elements
• Application: gas and potable water distribution, service connections, pipeline repair

How to use

Select a compatible electrofusion control box and follow the manufacturer’s fusion parameters for PE100 SDR11 63 mm connections. Prepare the host pipe by cleaning and removing the external layer and any contaminants at the fusion zone, then position the saddle concentrically on the pipe and clamp securely. Connect the control unit to the saddle’s terminals, start the programmed fusion cycle and allow the heating sequence and subsequent cooling time to complete before releasing clamps or applying pressure to the new branch.

Usage recommendations

Use certified electrofusion equipment and adhere to applicable installation standards and safety procedures. Verify that the saddle size and SDR are compatible with the existing pipeline and perform visual and pressure tests after fusion to confirm joint integrity. Store fittings in a cool, dry place away from direct sunlight and inspect for damage prior to use.
