AV receiver Vivolink VL120016R Black

Connectivity technology:

Wired

HDCP pass-through:

Yes

RS-232 pass-through:

Yes

CEC pass-through:

Yes

Ports & interfaces

Serial interface type:

RS-232

Serial ports quantity:

1

DC-in jack:

Yes

HDMI in:

1

Number of HDMI outputs:

1

Remote (IR) input:

1

Remote (IR) output:

1

RJ-45 input ports:

1

3.5 mm (1/8-inch) in:

Yes

RS-232 input ports:

1

RS-232 output ports:

1

3.5 mm (1/8-inch) out:

Yes

Video in:

1

Video out:

1

HDMI version:

1.4

Consumer Electronics Control (CEC) support:

Yes

Video

Bandwidth:

10.2 Gbit/s

Technical details

Type:

AV receiver

Wall mountable:

Yes

Maximum transfer distance:

70 m

Audio support:

Yes

HDCP & EDID bypass:

Yes

IR pass-through:

Yes

HDBaseT certified:

Yes

Power

Power over Ethernet (PoE):

Yes

Output current:

1.25 A

Operating voltage:

24 V

AC input frequency:

50 - 60

AC input voltage:

100 - 240

Power consumption (receiver) (max):

11 W

Weight & dimensions

Weight:

0.208 kg

Height:

16.2 mm

Width:

115 mm

Depth:

84 mm

Operational conditions

Operating relative humidity (H-H):

10 - 90

Operating temperature (T-T):

-20 - 70

Packaging data

Package weight:

308 g

Package depth:

151 mm

Package height:

81 mm

Package width:

152 mm

Included power plug types:

EU

Packaging content

AC adapter included:

Yes

Mounting brackets included:

Yes

IR blaster included:

No

IR receiver included:

No

Features

LED indicators:

Y

Product colour:

Black

External power adapter:

Yes

Remote control type:

IR + RS232

Supported video modes:

3840p

HDCP:

Yes

3D:

Yes

HDCP version:

2.2

Network

Cable types supported:

Cat5e
