VivoLink VLEXTA170 AV Transmitter and Receiver Wired Cat5e 100 m Black

Connectivity technology: The technology that enables connectivity of the device, e.g. wired or wireless.

Wired

Technical details

Audio support:

Yes

Maximum transfer distance: The greatest distance over which the data/signal can be transferred.

100 m

HDCP & EDID bypass:

Yes

IR pass-through:

Yes

Type: Characteristics of the device.

AV transmitter & receiver

Wall mountable: The product can be mounted on (attached to ) a wall.

Yes

Audio input: The type of audio input that the device requires, and the connection needed.

3

Audio output: The type of audio output that the device produces, and the connector(s).

3

Packaging data

Package height: The distance from the top to the bottom of the packaging.

120 mm

Package width: The distance from one side of the packaging to the other.

156 mm

Package weight: Weight of the packaged product.

484 g

Package depth: The distance from the front to the back of the packaging.

155 mm

Included power plug types:

EU

Weight & dimensions

Transmitter dimensions (WxDxH):

88 x 80 x 21.5

Weight: Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies.

0.24 kg

Height: The measurement of the product from head to foot or from base to top.

21.5 mm

Depth: The distance from the front to the back of something.

80 mm

Width: The measurement or extent of something from side to side.

80 mm

Operational conditions

Operating relative humidity (H-H):

10 - 90

Operating temperature (T-T): The minimum and maximum temperatures at which the product can be safely operated.

-10 - 55

Packaging content

IR blaster included:

No

AC adapter included:

Yes

Mounting brackets included:

Yes

IR receiver included:

No

Audio

Audio output channels: An audio output channel is an electric circuit which acts as a path for a signal produced by a device. A device may have several audio output channels.

2.0

Ports & interfaces

Audio RCA outputs:

1

DC-in jack: The socket/plug where the DC electricity supply connects to the device.

Yes

Video in:

1

Video out:

1

3.5 mm (1/8-inch) out:

Yes

3.5 mm (1/8-inch) in:

Yes

RJ-45 output ports:

1

RJ-45 input ports:

1

Digital audio coaxial out: The socket in the device for the digital audio output. The signal is carried via a coaxial cable with an RCA connector.

1

Audio (L/R) out: The two sockets (ports) for transmitting left audio signal (white cable) and right audio signal (red cable).

1

Power

Power consumption (receiver) (max):

2.5 W

Power consumption (transmitter) (max):

2.5 W

Operating voltage (transmitter):

12 V

Operating voltage (receiver):

12 V

Output current:

1 A

AC input frequency:

50/60

AC input voltage: The voltage of the AC electricity that is inputted into the product.

100 - 240

Network

Cable types supported:

Cat5e

Features

LED indicators:

Y

Audio formats supported: The audio formats which this device or software can read/use e.g. MP3, MP4.

PCM

External power adapter:

Yes

Product colour: The colour e.g. red, blue, green, black, white.

Black
