Weight:
Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies.
-
0.9 kg
-
Power consumption (typical):
Amount of power consumed by this model, often expressed in watts (W). Typical values that manufacturers give are power consumption when off, standby/suspended mode, typical use, maximum usage.
-
12 W
-
Security algorithms:
Security algorithms are used to provide authentication, cipher key generation, integrity and radio link privacy to users on mobile networks. The security algorithms supported are the ones that can be used with this product.
-
FIPS 140-3, IPSec, HTTPS
-
Mean time between failures (MTBF):
Statistical model used to indicate product/mechanism reliability; expressed in hours and percentage of duty cycle. This number (in hours) does not indicate the mean time before failure for a single unit/mechanism.
-
1101388 h
-
Operating altitude:
-
0 - 3000
-
Operating relative humidity (H-H):
-
10 - 85
-
Storage temperature (T-T):
The minimum and maximum temperatures at which the product can be safely stored.
-
-40 - 70
-
Package weight:
Weight of the packaged product.
-
1400 g
-
Form factor:
The shape or design of the product.
-
Desktop
-
Operating temperature (T-T):
The minimum and maximum temperatures at which the product can be safely operated.
-
0 - 40
-
Serial ports quantity:
The number of serial ports in a computer or peripheral. A serial port is a serial communication physical interface through which information transfers in or out one bit at a time. The term "serial port" usually identifies hardware more or less compliant to the RS-232 standard, intended to interface with a modem or with a similar communication device. In modern computers and peripherals, serial ports have largely been replaced by USBs and other interfaces.
-
1
-
Storage relative humidity (H-H):
-
10 - 85
-
Height:
The measurement of the product from head to foot or from base to top.
-
32 mm
-
LED indicators:
-
Y
-
WAN connection:
A wide area network (WAN) is a network that covers a broad area (i.e. any telecommunications network that links across metropolitan, regional, or national boundaries such as the Internet) using private or public network transports. Business and government entities utilize WANs to relay data among employees, clients, buyers, and suppliers from various geographical locations.
-
Ethernet (RJ-45)
-
Routing protocols:
-
RIP, OSPF, BGP
-
Width:
The measurement or extent of something from side to side.
-
190 mm
-
Depth:
The distance from the front to the back of something.
-
152 mm
-
Connectivity technology:
The technology that enables connectivity of the device, e.g. wired or wireless.
-
Wired
-
Number of users:
The number of people that use or can use this product.
-
5 user(s)
-
Networking standards:
The way in which the network is working, e.g. IEEE 802.11a, IEEE 802.11b, IEEE 802.11g.
-
IEEE 802.1Q
-
USB 2.0 ports quantity:
Number of USB 2.0 ports (connecting interfaces) in the device. USB 2.0 was released in April 2000 (now called "Hi-Speed"), adding higher maximum signaling rate of 480 Mbit/s (effective throughput up to 35 MB/s or 280 Mbit/s), USB 2.0 ports are usually black.
-
1
-
Ethernet LAN (RJ-45) ports:
Number of Ethernet LAN (RJ-45) ports (connecting interfaces) in the device. Ethernet LAN (RJ-45) ports allow a computer to connect to the ethernet.
-
3
-
DC-in jack:
The socket/plug where the DC electricity supply connects to the device.
-
Yes
-
Quality of Service (QoS) support:
-
Yes
-
DHCP client:
Whether the product features a DHCP (Dynamic Host Configuration Protocol) to obtain IP addresses within a network.
-
Yes
-
DHCP server:
A server is a system which that responds to requests across a computer network to provide, or help to provide, a network service. DCHP servers uses the DCHP (Dynamic Host Configuration Protocol), which is a standardized networking protocol used by servers on an IP network to allocate IP addresses to computers. The purpose of DHCP is to automate the IP address configuration of a computer without a network administrator. IP addresses are typically selected from a range of assigned IP addresses stored in a database on the server and issued to a computer which requests a new IP address. An IP address is assigned to a computer for a set interval, after which, the computer must renew the IP address or acquire a new one.
-
Yes
-
Ethernet LAN data rates:
The different speed levels of the Ethernet LAN connection.
-
1000, 10, 100
-
Reset button:
-
Yes
-
Package depth:
The distance from the front to the back of the packaging.
-
261 mm
-
Package height:
The distance from the top to the bottom of the packaging.
-
181 mm
-
Package width:
The distance from one side of the packaging to the other.
-
308 mm
-
Concurrent connections:
-
73000
-
On/off switch:
The button which is pressed to switch the device on or off.
-
Yes
-
Number of VLANs:
-
10
-
Branch Office VPN:
-
5
-
AC input voltage:
The voltage of the AC electricity that is inputted into the product.
-
100-240
-
DC input voltage:
-
12
-
Maximum firewall connections per second:
-
8500
-
Dynamic DNS (DDNS):
-
Yes
-
Point-to-point protocol over Ethernet (PPPoE):
The Point-to-Point Protocol over Ethernet (PPPoE) is a network protocol for encapsulating PPP frames inside Ethernet frames. It appeared in 1999, in the context of the boom of DSL as the solution for tunneling packets over the DSL connection to the ISP's IP network, and from there to the rest of the Internet. A 2005 networking book noted that "Most DSL providers use PPPoE, which provides authentication, encryption, and compression." Typical use of PPPoE involves leveraging the PPP facilities for authenticating the user with a username and password, predominately via the PAP protocol and less often via CHAP.
-
Yes
-
Static route:
-
Yes
-
Dynamic routing:
-
Yes
-
VPN (IMIX) throughput:
-
62 Mbit/s
-
Firewall (UDP 1518) throughput:
-
0.41 Gbit/s
-
VPN (UDP 1518) throughput:
-
0.2 Gbit/s
-
WSM license quantity:
-
0 license(s)
-
Firewall throughput:
-
1.5 Gbit/s
-
Compliance certificates:
Indicates which regulatory, safety, and environmental standards the product complies with, as verified by recognized authorities or certification bodies.
-
REACH, RoHS, WEEE, CB
