Handheld bar code reader Motorola LS1203

Name: Handheld bar code reader Motorola LS1203-7AZU0100ER
Brand: Zebra
SKU: 240308
Price: 49.22 EUR
Availability: OutOfStock

Dreame – powerful cleaning with ease

Dreame vacuums for fast and efficient cleaning!

Short description

The Motorola LS1203 is a handheld bar code reader featuring a laser sensor for scanning linear (1D) barcodes including Codabar, Code 11, Code 128, Code 39, Code 93, and GS1-128. It connects via USB and operates on a 5V DC power source with a consumption of 100 mA. Weighing only 122 g and measuring 60.9 mm in width and 180.3 mm in depth, it is lightweight and easy to handle, making it ideal for retail and inventory management.

Warranty: 2 Years

SKU: 240308

Information regarding the items availability for purchase will be posted on this site

Item cost information will be published on this site

You saving {{productBundleYouSave | formatAmount}}

Product information

Description

The Motorola LS1203 handheld bar code reader is a laser-based 1D scanner designed for retail and inventory tasks. It reads common linear barcodes including GS1-128, Code 128, Code 39, Code 93, Codabar and Code 11. The scanner connects via USB and also supports RS232 and keyboard wedge interfaces, offering plug-and-play connectivity and easy integration with point-of-sale and PC systems. Its single-board construction and drop resistance reduce downtime and repair costs while the lightweight ergonomic housing supports extended use.

Advantages

The LS1203 minimizes manual data entry and improves transaction accuracy by reliably capturing 1D barcodes at high speed. Durable single-board construction meets 5-foot drop tests for increased reliability. Multiple onboard interfaces (USB, RS232, keyboard wedge) simplify installation and future compatibility. The ergonomic, lightweight design and choice of triggered or continuous scanning modes reduce user fatigue and speed workflow.

Suitable for

Retail point-of-sale scanning
Stockroom and inventory counting
Price verification and shelf labeling
Basic warehousing tasks that require 1D barcode capture

Key specifications

Sensor type: Laser
Supported barcode types: Linear (1D) — GS1-128, Code 128, Code 93, Code 39, Codabar, Code 11
Read rate: Up to 100 reads/s
Connectivity: USB, RS232, keyboard wedge
Power: 5 V DC, 100 mA consumption
Weight: 0.122 kg
Colour: Black

How to use

Connect the LS1203 to the host system using the appropriate interface cable (USB, RS232 or keyboard wedge). Position the scanner so the laser aims at the barcode and press the trigger in triggered mode, or switch to continuous mode for hands-free scanning. Ensure the scanner is within recommended working distance from the barcode and align the laser across the full barcode to capture a clean read. The device operates with standard USB or serial drivers and requires minimal setup for plug-and-play operation.

Usage recommendations

The scanner is intended for 1D barcode capture; do not expect reliable performance on 2D matrix or stacked codes. For best results, keep the scanner lens clean, avoid extreme angles when aiming at barcodes, and choose triggered mode for occasional reads or continuous mode for high-volume scanning tasks.

Specifications

Sensor type:: Laser
Read rate (max):: 100 reads/s
Connectivity technology:: Wired
Weight:: 0.122 kg
Linear (1D) barcodes supported:: GS1-128 (UCC/EAN-128), Code 93, Codabar, Code 11, Code 128, Code 39
2D (matrix & stacked) barcodes supported:: Not supported
Product colour:: Black

All features

Scanning

Sensor type:: Laser
Type:: Handheld bar code reader
Read rate (max):: 100 reads/s
Linear (1D) barcodes supported:: GS1-128 (UCC/EAN-128), Code 93, Codabar, Code 11, Code 128, Code 39
2D (matrix & stacked) barcodes supported:: Not supported
Wavelength:: 650 nm
Tilt reading angle:: -30 - 30

Ports & interfaces

Connectivity technology:: Wired
Standard interfaces:: USB

Power

Input voltage:: 5
Power consumption:: 100 mA
Power source type:: DC

Performance

Product colour:: Black

Weight & dimensions

Weight:: 0.122 kg
Height:: 60.9 mm
Width:: 60.9 mm
Depth:: 180.3 mm

Operational conditions

Operating relative humidity (H-H):: 5 - 95
Storage temperature (T-T):: -40 - 70
Operating temperature (T-T):: 0 - 50

Logistics data

Harmonized System (HS) code:: 84716070

Packaging data

Cables included:: USB
