Type:
Characteristics of the device.
-
Built-in bar code reader
-
Weight:
Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies.
-
0.577 kg
-
Scanner type:
Indicates the type of scanner this product is.
-
1D/2D
-
Operating relative humidity (H-H):
-
20 - 95
-
Storage temperature (T-T):
The minimum and maximum temperatures at which the product can be safely stored.
-
-40 - 70
-
Operating temperature (T-T):
The minimum and maximum temperatures at which the product can be safely operated.
-
0 - 50
-
Height:
The measurement of the product from head to foot or from base to top.
-
137 mm
-
Input voltage:
The voltage (V) which is required to power the product.
-
5
-
Width:
The measurement or extent of something from side to side.
-
152 mm
-
Depth:
The distance from the front to the back of something.
-
84 mm
-
Connectivity technology:
The technology that enables connectivity of the device, e.g. wired or wireless.
-
Wired
-
Product colour:
The colour e.g. red, blue, green, black, white.
-
Black
-
Wavelength:
The distance over which a wave repeats itself. The wavelength determines the characteristics of the wave e.g. red light has a different wavelength to blue light.
-
660 nm
-
Light levels (direct sunlight):
-
0 - 86100
-
International Protection (IP) code:
The IP code classifies and rates the degree of protection provided against the intrusion (including body parts such as hands and fingers), dust, accidental contact, and water by mechanical casings and electrical enclosures. It is published by the International Electrotechnical Commission (IEC). The digits (characteristic numerals) indicate conformity with the conditions summarized in the tables below. Where there is no protection rating with regard to one of the criteria, the digit is replaced with the letter X. an electrical socket rated IP22 is protected against insertion of fingers and will not be damaged or become unsafe during a specified test in which it is exposed to vertically or nearly vertically dripping water. Another example is the Sony Xperia Z Ultra, one of the first cellular phones to be IP-rated; it is rated at IP58 and marketed as "dust resistant" and can be "immersed in 1.5 meter of freshwater for up to 30 minutes".
-
IP52
-
Standard interfaces:
Most common industry-standard communication protocols ranging from RS-232, RS-422, RS-423, RS-485, and LVDS to USB.
-
USB
-
Power source type:
What the power source is.
-
DC
-
Linear (1D) barcodes supported:
The product can read linear (1D) barcordes.
-
Code 93, Codabar, Code 11, Code 128, Code 39, GS1 DataBar, MSI, Plessey, UPC-A
-
2D (matrix & stacked) barcodes supported:
The product can read matrix (2D) barcordes.
-
Micro QR Code, MicroPDF417, PDF417, QR Code, TLC-39, MaxiCode, Aztec Code, Composite Codes, Data Matrix, Han Xin
-
Optical sensor resolution (W x H):
-
1920 x 1200
