Viewing angle, horizontal:
Maximum horizontal angle at which a display can be viewed with acceptable visual performance.
-
156 °
-
Viewing angle, vertical:
Maximum vertical angle at which a display can be viewed with acceptable visual performance.
-
116 °
-
Weight:
Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies.
-
0.355 kg
-
Supported network protocols:
Network protocols tested as compatible with this product e.g. FTP,HTML, POP.
-
RTP, RTSP, SRTP
-
Operating relative humidity (H-H):
-
10 - 95
-
Cabling technology:
Type of cable technology performance.
-
10/100Base-T(X)
-
Storage temperature (T-T):
The minimum and maximum temperatures at which the product can be safely stored.
-
-40 - 70
-
AC adapter input voltage:
-
20
-
AC adapter output voltage:
-
12
-
AC adapter output current:
-
2 A
-
Built-in microphone:
Microphone that is found inside the product.
-
Yes
-
Operating temperature (T-T):
The minimum and maximum temperatures at which the product can be safely operated.
-
-40 - 60
-
Height:
The measurement of the product from head to foot or from base to top.
-
172 mm
-
Sensor type:
A sensor is a convertor than measures a physical quality (light, temperature etc.) and displays this electronically on a device.
-
CMOS
-
Minimum illumination:
Also known as light sensitivity, this is the smallest amount of light needed for the camera to produce an image of useable quality.
-
0.3 lx
-
Display resolution:
The number of distinct pixels in each dimension that can be displayed. It is usually quoted as width × height, with the units in pixels: for example, "1024 × 768" means the width is 1024 pixels and the height is 768 pixels. The higher the number of pixels, the sharper the image.
-
1920 x 1440
-
Optical sensor size:
Optical sensors are electronic detectors that convert light, or a change in light, into an electronic signal. They are used in many industrial and consumer applications e.g. lamps that turn on automatically in response to darkness. Optical sensors come in many sizes.
-
25.4 / 2.7
-
Width:
The measurement or extent of something from side to side.
-
78 mm
-
Depth:
The distance from the front to the back of something.
-
53 mm
-
Connectivity technology:
The technology that enables connectivity of the device, e.g. wired or wireless.
-
Wired & Wireless
-
Speaker power:
-
3 W
-
Product colour:
The colour e.g. red, blue, green, black, white.
-
Grey
-
Networking standards:
The way in which the network is working, e.g. IEEE 802.11a, IEEE 802.11b, IEEE 802.11g.
-
IEEE 802.3af
-
Speakerphone:
Device has a microphone and loudspeaker provided separately from those in the handset. This device allows multiple persons to participate in a conversation. The loudspeaker broadcasts the voice or voices of those on the other end of the telephone line, while the microphone captures all voices of those using the speakerphone.
-
Yes
-
Voice codecs:
-
G.711, G.722, G.729
-
Ethernet LAN (RJ-45) ports:
Number of Ethernet LAN (RJ-45) ports (connecting interfaces) in the device. Ethernet LAN (RJ-45) ports allow a computer to connect to the ethernet.
-
1
-
Built-in speaker(s):
The device contains speaker(s) to produce sound.
-
Yes
-
Control type:
The way in which the device is controlled.
-
Buttons
-
Proper use:
The intended application of the product.
-
Outdoor
-
Power over Ethernet (PoE):
The device supports Power over Ethernet (PoE), which is one of several standardized or ad-hoc systems which pass electrical power along with data on Ethernet cabling. This allows a single cable to provide both data connection and electrical power to devices such as wireless access points or IP cameras.
-
Yes
-
Placement supported:
Where the product can be placed e.g. indoor/outdoor, horizontal/vertical.
-
Vertical
-
Ethernet LAN data rates:
The different speed levels of the Ethernet LAN connection.
-
100, 10
-
Video codecs:
-
H.264, MJPEG, Zipstream
-
Housing material:
What the casing of the product is made of.
-
Aluminium
-
Power consumption:
-
600 mA
-
Fixed focal length:
-
1.93 mm
-
Ethernet interface type:
-
Fast Ethernet
-
Maximum frame rate:
This is the maximum frame rate, also known as frame frequency and frames per second (FPS). It is the frequency (rate) at which an imaging device produces unique consecutive images called frames. The term applies equally well to film and video cameras, computer graphics, and motion capture systems. Frame rate is most often expressed in frames per second (FPS) and is also expressed in progressive scan monitors as hertz (Hz).
-
30 fps
-
International Protection (IP) code:
The IP code classifies and rates the degree of protection provided against the intrusion (including body parts such as hands and fingers), dust, accidental contact, and water by mechanical casings and electrical enclosures. It is published by the International Electrotechnical Commission (IEC). The digits (characteristic numerals) indicate conformity with the conditions summarized in the tables below. Where there is no protection rating with regard to one of the criteria, the digit is replaced with the letter X. an electrical socket rated IP22 is protected against insertion of fingers and will not be damaged or become unsafe during a specified test in which it is exposed to vertically or nearly vertically dripping water. Another example is the Sony Xperia Z Ultra, one of the first cellular phones to be IP-rated; it is rated at IP58 and marketed as "dust resistant" and can be "immersed in 1.5 meter of freshwater for up to 30 minutes".
-
IP66
-
Number of buttons:
The quantity of buttons, which are small device on a piece of electrical or electronic equipment which are pressed to operate it.
-
1 buttons
-
Wide Dynamic Range (WDR):
-
Yes
-
Backlight buttons:
-
Yes
-
Vandal-proof:
Product is designed to be installed in a location (or device) and application where they may be subject to vandalism or tampering.
-
Yes
-
Number of speakers:
The quantity of speakers included in/with the product.
-
1
-
Maximum number of cameras supported:
The total number of cameras that can be used with the product.
-
1
-
IK code:
-
IK08
-
Display aspect ratio:
-
4:3
-
Quantity per pack:
-
1 pc(s)
-
Smartphone support:
-
Yes
-
Outdoor unit included:
-
Yes
-
Outdoor unit power type:
-
DC/PoE
-
Warranty period:
-
5 year(s)
