Almeva stove pipe elbow 45° DN60 (DWZ) by Almeva, model PPSB45

Almeva stove pipe elbow 45° DN60 (DWZ) is a smooth-walled angled connector for domestic flue and stove pipe systems. It provides a 45-degree change of direction for DN60 (60 mm nominal) ducts and is compatible with other DWZ components. The elbow is intended for use where a compact routing or a gentle change of direction is required to maintain proper draft and ensure safe exhaust of combustion gases from stoves, boilers or furnaces.

Advantages

The 45° elbow offers reduced resistance compared with sharper bends, helping to preserve flue draft and reduce the risk of soot accumulation. Its smooth-walled (DWZ) construction facilitates easier passage of exhaust gases and simpler cleaning. The component is designed for direct connection to DN60 stove pipe systems, providing a tight fit and stable alignment for reliable operation in domestic heating installations.

Suitable for

• Redirecting stove or furnace flue pipes in compact installations
• Connecting DN60 smooth-walled (DWZ) duct sections
• Adjusting flue alignment to pass around obstacles or fit into flue runs
• Applications where gradual directional change improves draft and reduces deposition

Key specifications

• Nominal diameter: DN60 (60 mm)
• Angle: 45 degrees
• Wall type: smooth-walled (DWZ)
• Application area: stove and domestic flue pipe systems
• Connection: designed for direct fit with DN60 DWZ components

How to use

Fit the Almeva 45° elbow inline with DN60 stove pipe sections, ensuring mating ends are clean and free of debris before assembly. Align the elbow to create the required directional change and push or join the component according to the stove pipe system's connection method. Verify that joints are secure and correctly seated to maintain an effective seal and stable alignment. Follow local building codes and the stove or chimney manufacturer's instructions when integrating the elbow into an existing flue system.

Usage recommendations

Inspect and clean the flue system regularly to prevent soot and creosote buildup; use the 45° elbow where a gradual bend is preferred to preserve draft. Confirm compatibility with other DN60 DWZ components and follow safety guidelines for combustion appliance exhaust systems.
