ALNOR ILSL-200 Flat Branch with Gaskets 200 mm

The ALNOR ILSL-200 is a high-quality flat branch piece engineered for seamless integration into ventilation systems. With a diameter of 200 mm, this component is specifically designed to facilitate efficient airflow distribution within ductwork installations. It features integrated gaskets that ensure a secure, airtight connection, minimizing pressure loss and preventing air leakage throughout the system.

Advantages

This flat branch piece stands out due to its robust construction, which ensures long-term durability even in demanding HVAC environments. The inclusion of factory-fitted gaskets simplifies the installation process significantly, as it eliminates the need for additional sealing materials while maintaining high airtightness standards. Its precise design allows for smooth airflow, contributing to the overall energy efficiency and performance of the ventilation network.

Suitable for

• Residential ventilation systems
• Commercial HVAC ductwork installations
• Air distribution branches in industrial facilities
• Professional ventilation maintenance and repair projects

When it may not be suitable

This component is not intended for use in systems carrying corrosive gases, high-temperature industrial exhaust, or environments with extreme chemical exposure. It is also not suitable for non-standard duct diameters outside of the 200 mm specification.

Key specifications

• Diameter: 200 mm
• Material: Galvanized steel
• Connection type: Flat branch with integrated gaskets
• Compatibility: Standard circular ventilation ducts

How to use

To install the ALNOR ILSL-200, ensure the ductwork is clean and free of debris. Align the branch piece with the main duct opening and slide it into position. The integrated gaskets will provide a tight seal upon insertion. Secure the connection using appropriate mechanical fasteners or screws as required by local building codes to ensure structural stability. Verify that the connection is airtight before finalizing the installation.

What to consider before purchase

• Verify that your existing ductwork diameter is exactly 200 mm.
• Ensure the branch configuration matches your system layout requirements.
• Check if additional mounting brackets are needed for your specific installation setup.

Usage recommendations

Regularly inspect the connection points of your ventilation system for signs of wear or vibration. Ensure that the ductwork is properly supported to prevent excessive stress on the branch piece.
