Weight:
Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies.
-
0.645 kg
-
Certification:
-
UL 2043
UL294
EAC, EN 55035, EN 55032 Class B, EN 50130-4, EN 61000-3-2,
EN 61000-3-3, FCC Part 15 Subpart B Class A, ICES-003 Class A,
VCCI Class A, RCM AS/NZS CISPR 32 Class A, KC KN32 Class B,
KC KN35
IEC/EN/UL 62368-1, UL 294, UL 2043
Environment
NEMA TS 2 (2.2.7-2.2.9), IEC 60068-2-1, IEC 60068-2-2,
IEC 60068-2-6, IEC 60068-2-14, IEC 60068-2-27,
IEC 60068-2-78
CSA C22.2 No. 205-1983
-
Supported network protocols:
Network protocols tested as compatible with this product e.g. FTP,HTML, POP.
-
IPv4, IPv6, HTTP, HTTPSc, TLSc, QoS Layer 3 DiffServ, SMTP, mDNS (Bonjour), UPnP®, SNMP v1/v2c/v3 (MIB-II), DNS/DNSv6, DDNS, NTP, RTSP, RTCP, RTP, TCP, UDP, IGMPv1/v2/v3, DHCPv4/v6, SOCKS, SSH, MQTT v3.1.1, Syslog
-
Operating relative humidity (H-H):
-
20 - 85
-
Storage temperature (T-T):
The minimum and maximum temperatures at which the product can be safely stored.
-
-40 - 70
-
Operating temperature (T-T):
The minimum and maximum temperatures at which the product can be safely operated.
-
0 - 55
-
Ethernet LAN:
An Ethernet LAN (Local Area Network) interface is present, for a wired conection via a cable.
-
Yes
-
Height:
The measurement of the product from head to foot or from base to top.
-
50 mm
-
Width:
The measurement or extent of something from side to side.
-
144 mm
-
Depth:
The distance from the front to the back of something.
-
122 mm
-
Ethernet LAN (RJ-45) ports:
Number of Ethernet LAN (RJ-45) ports (connecting interfaces) in the device. Ethernet LAN (RJ-45) ports allow a computer to connect to the ethernet.
-
1
-
Case design:
-
Housing
-
Ethernet LAN data rates:
The different speed levels of the Ethernet LAN connection.
-
1000, 100, 10
-
Operating voltage:
Defines the range of operating voltages available
-
12 V
-
DC voltage range:
-
11.5 - 12.5
-
Internal storage capacity:
The amount e.g of data which can be stored inside the device.
-
2 GB
-
Maximum number of doors:
The maximum quantity of doors supported by device.
-
1 door(s)
-
Internal memory:
A computer's memory which is directly accessible to the CPU.
-
0.512 GB
-
Storage media:
Used for the storage of data e.g. HDD (hard disk drive), SSD (solid-state drive).
-
Flash
-
Alarm input channels:
-
7
-
Number of built-in relays:
-
1
-
Wiegand interface:
-
Yes
