Viewing angle, horizontal:
Maximum horizontal angle at which a display can be viewed with acceptable visual performance.
-
150 °
-
Viewing angle, vertical:
Maximum vertical angle at which a display can be viewed with acceptable visual performance.
-
112 °
-
Colour:
The main colour of the product.
-
Yes
-
Weight:
Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies.
-
2.069 kg
-
Power consumption (typical):
Amount of power consumed by this model, often expressed in watts (W). Typical values that manufacturers give are power consumption when off, standby/suspended mode, typical use, maximum usage.
-
7 W
-
Supported network protocols:
Network protocols tested as compatible with this product e.g. FTP,HTML, POP.
-
IPv4, IPv6 USGv6, ICMPv4/ICMPv6, HTTP, HTTPS2, HTTP/ 2, TLS2, QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP®, SNMP v1/v2c/v3 (MIB- II), DNS/DNSv6, DDNS, NTP, PTP, NTS, RTSP, RTP, SRTP/ RTSPS, TCP, UDP, IGMPv1/v2/v3, RTCP, ICMP, DHCPv4/ v6, ARP, SSH, LLDP, CDP, MQTT v3.1.1, Secure syslog (RFC 3164/5424, UDP/TCP/TLS), Link-Local address (ZeroConf)
-
Operating relative humidity (H-H):
-
5 - 95
-
Compatible memory cards:
Types of memory cards which can be used with this product.
-
MicroSDXC, MicroSDHC, MicroSD (TransFlash)
-
Cabling technology:
Type of cable technology performance.
-
10/100Base-T(X)
-
Storage temperature (T-T):
The minimum and maximum temperatures at which the product can be safely stored.
-
-40 - 65
-
Display diagonal:
Size of the display for this product, measured diagonally, usually in inches.
-
7 "
-
Built-in microphone:
Microphone that is found inside the product.
-
Yes
-
Operating temperature (T-T):
The minimum and maximum temperatures at which the product can be safely operated.
-
-30 - 55
-
Height:
The measurement of the product from head to foot or from base to top.
-
290 mm
-
Sensor type:
A sensor is a convertor than measures a physical quality (light, temperature etc.) and displays this electronically on a device.
-
CMOS
-
Minimum illumination:
Also known as light sensitivity, this is the smallest amount of light needed for the camera to produce an image of useable quality.
-
0.04 lx
-
Display resolution:
The number of distinct pixels in each dimension that can be displayed. It is usually quoted as width × height, with the units in pixels: for example, "1024 × 768" means the width is 1024 pixels and the height is 768 pixels. The higher the number of pixels, the sharper the image.
-
800 x 480
-
Optical sensor size:
Optical sensors are electronic detectors that convert light, or a change in light, into an electronic signal. They are used in many industrial and consumer applications e.g. lamps that turn on automatically in response to darkness. Optical sensors come in many sizes.
-
25.4 / 1.8
-
Wall mountable:
The product can be mounted on (attached to ) a wall.
-
Yes
-
Width:
The measurement or extent of something from side to side.
-
144 mm
-
Depth:
The distance from the front to the back of something.
-
44 mm
-
Connectivity technology:
The technology that enables connectivity of the device, e.g. wired or wireless.
-
Wired
-
Product colour:
The colour e.g. red, blue, green, black, white.
-
Black
-
Networking standards:
The way in which the network is working, e.g. IEEE 802.11a, IEEE 802.11b, IEEE 802.11g.
-
IEEE 802.3at, IEEE 802.3af
-
Speakerphone:
Device has a microphone and loudspeaker provided separately from those in the handset. This device allows multiple persons to participate in a conversation. The loudspeaker broadcasts the voice or voices of those on the other end of the telephone line, while the microphone captures all voices of those using the speakerphone.
-
Yes
-
Voice codecs:
-
PCM, G.726, G.711
-
Built-in speaker(s):
The device contains speaker(s) to produce sound.
-
Yes
-
Control type:
The way in which the device is controlled.
-
Touch
-
Power over Ethernet (PoE):
The device supports Power over Ethernet (PoE), which is one of several standardized or ad-hoc systems which pass electrical power along with data on Ethernet cabling. This allows a single cable to provide both data connection and electrical power to devices such as wireless access points or IP cameras.
-
Yes
-
Placement supported:
Where the product can be placed e.g. indoor/outdoor, horizontal/vertical.
-
Vertical
-
Ethernet LAN data rates:
The different speed levels of the Ethernet LAN connection.
-
100, 10
-
Quick start guide:
Instructions, either online, as a computer program or in paper form, to allow you to set up and start using the product quickly.
-
Yes
-
On Screen Display (OSD) languages:
-
Multi
-
Touchscreen:
A screen of a laptop, smartphone, etc., that responds to touch so you can control the interface using your fingers.
-
Yes
-
Housing material:
What the casing of the product is made of.
-
Aluminium
-
Maximum aperture number:
-
1.8
-
Fixed focal length:
-
2.2 mm
-
Video formats supported:
The type of video formats that can be used by this device.
-
MPEG4, H.265, H.264
-
Echo cancellation:
-
Yes
-
Ethernet interface type:
-
Fast Ethernet
-
Maximum video resolution:
This is the maximum resolution of video images. Resolution is a measure of the degree of detail visible.
-
3840 x 2160
-
Maximum frame rate:
This is the maximum frame rate, also known as frame frequency and frames per second (FPS). It is the frequency (rate) at which an imaging device produces unique consecutive images called frames. The term applies equally well to film and video cameras, computer graphics, and motion capture systems. Frame rate is most often expressed in frames per second (FPS) and is also expressed in progressive scan monitors as hertz (Hz).
-
60 fps
-
PTZ control:
-
Yes
-
International Protection (IP) code:
The IP code classifies and rates the degree of protection provided against the intrusion (including body parts such as hands and fingers), dust, accidental contact, and water by mechanical casings and electrical enclosures. It is published by the International Electrotechnical Commission (IEC). The digits (characteristic numerals) indicate conformity with the conditions summarized in the tables below. Where there is no protection rating with regard to one of the criteria, the digit is replaced with the letter X. an electrical socket rated IP22 is protected against insertion of fingers and will not be damaged or become unsafe during a specified test in which it is exposed to vertically or nearly vertically dripping water. Another example is the Sony Xperia Z Ultra, one of the first cellular phones to be IP-rated; it is rated at IP58 and marketed as "dust resistant" and can be "immersed in 1.5 meter of freshwater for up to 30 minutes".
-
IP66
-
Image quality adjustment:
-
White balance, Sharpness, Saturation, Mirror, Contrast, Brightness
-
Touchscreen type:
There are a variety of touchscreen technologies that have different methods of sensing touch, including resistive and capacitive.
-
Capacitive
-
Wide Dynamic Range (WDR):
-
Yes
-
Power consumption (max):
The maximum amount of power used by the device.
-
25 W
-
Streaming capability:
-
Yes
-
Motion sensor:
Device that detects moving objects, particularly people. A motion detector is often integrated as a component of a system that automatically performs a task or alerts a user of motion in an area. Motion detectors form a vital component of security, automated lighting control, home control, energy efficiency, and other useful systems.
-
Yes
-
Vandal-proof:
Product is designed to be installed in a location (or device) and application where they may be subject to vandalism or tampering.
-
Yes
-
Number of displays supported:
The number of displays that can be used with this product.
-
1
-
Maximum number of cameras supported:
The total number of cameras that can be used with the product.
-
1
-
IK code:
-
IK08
-
Screws included:
-
Yes
-
RFID reader:
-
Yes
-
Motion sensor technology:
-
Passive infrared (PIR) sensor
-
Quantity per pack:
-
1 pc(s)
-
Outdoor unit included:
-
Yes
-
Outdoor unit power type:
-
DC/PoE
-
Flash memory (transmitter):
-
8 MB
-
Internal memory (transmitter):
-
4000 MB
-
Alarm input channels (transmitter):
-
4
