Short description

The D-Link Wireless AC1200 Wave 2 Dual Band Outdoor PoE Access Point DAP-3666 supports 2.4GHz and 5GHz bands with a maximum data transfer rate of 1200 Mbit/s. It features robust security algorithms including 64-bit and 128-bit WEP, and supports Ethernet LAN data rates of 10/100/1000 Mbit/s. With Power over Ethernet (PoE) capability and a maximum power consumption of 10.5 W, this device is ideal for outdoor installations, providing reliable connectivity in various environments.

Available at price 216.99 €: 6 pcs.

Total available for order: 21 pcs.

Warranty: 2 Years

SKU: 3065837

Learn more

Deliver the order:

{{ userCountryName }}

to the Customer Service Center at Kengaraga 2b, Riga

13.07.2026 {{selectedOffer.officeDeliveryString}}

free

All delivery methods Hide details

Customer service center

2b. Kengaraga str., Riga, Latvia, LV-1063

13.07.2026 {{selectedOffer.officeDeliveryString}}

free

Courier Delivery Please note that in case of a large parcel additional delivery costs may apply!

16.07.2026 {{selectedOffer.courierDeliveryString}}

From 4.99 € (Weight: 1.73 kg)

Parcel couriers

Latvijas Pasts pakomāts / Unisend / DPD Paku skapis / Omniva / Venipak Pickup / Venipak Locker / Latvijas Pasts nodaļa

16.07.2026 {{selectedOffer.parcelStationDeliveryString}}

From 1.99 €

More about delivery methods

Payment Methods:

Cash payment, Bank transfer, Bank cards on-line, Apple Pay, Google Pay

Available for private customers at price 293.99 €: 6 pcs.

More about payment methods

You saving {{productBundleYouSave | formatAmount}}

Product information

Description

The D-Link DAP-3666 Wireless AC1200 Wave 2 Dual-Band Outdoor PoE Access Point is a weather-resistant outdoor access point supporting 2.4 GHz and 5 GHz bands with combined wireless rates up to 1200 Mbps. It supports MU-MIMO for simultaneous high-bandwidth connections, Passpoint® (Hotspot 2.0) for seamless network discovery and login, and Power over Ethernet (PoE) for simplified outdoor deployment. The device includes two Ethernet LAN ports and two external antennas and is suitable for creating outdoor wireless hotspot networks with centralised management via D-Link Nuclias Connect software or the Nuclias Connect Hub (DNH-100).

Advantages

The DAP-3666 delivers Wave 2 802.11ac performance with MU-MIMO to improve multi-client throughput and reduce contention. Its outdoor-hardened housing and PoE support simplify installation in challenging environments. Passpoint certification ensures automatic and secure user authentication for hotspot scenarios. Centralised management through Nuclias Connect allows remote configuration, monitoring and maintenance of multiple access points from a single interface.

Suitable for

Outdoor public hotspots (parks, plazas, tourist areas)
Campus and venue wireless extension
Outdoor coverage for cafes, hotels and venues
Remote sites requiring PoE-powered APs

Key specifications

Wireless standards: IEEE 802.11ac Wave 2, 802.11a/b/g/n
Bands: Dual-band 2.4 GHz and 5 GHz
Maximum combined wireless data rate: 1200 Mbit/s
MU-MIMO: supported
Security: WEP 64/128-bit and standard Wi‑Fi security protocols
Ethernet ports: 2 x RJ-45 (10/100/1000 Mbit/s)
Antennas: 2 external antennas
PoE: supported (IEEE 802.3af)
Power consumption: up to 10.5 W
Colour: White

How to use

Mount the DAP-3666 in a suitable outdoor location with line-of-sight to the coverage area and provide power and network connectivity via a PoE-enabled switch or PoE injector. Configure SSIDs, security settings and Passpoint/Hotspot 2.0 parameters using D-Link Nuclias Connect software or the Nuclias Connect Hub (DNH-100). Place the access point so that antennas are oriented according to site requirements and verify network operation through the management interface.

Usage recommendations

For best performance, separate SSIDs across 2.4 GHz and 5 GHz where density and client capability allow, position the AP to minimise physical obstructions, and use Nuclias Connect for centralised monitoring and firmware updates. Ensure PoE source meets IEEE 802.3af requirements and follow local regulations for outdoor mounting.

Specifications

Ethernet LAN (RJ-45) ports:: 2
Antennas quantity:: 2
Maximum data transfer rate:: 1200 Mbit/s
Product colour:: White
Networking standards:: IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3af, IEEE 802.11a

All features

Features

Mean time between failures (MTBF):: 30000 h
Cabling technology:: 10/100/1000Base-T(X)
Maximum data transfer rate:: 1200 Mbit/s
Frequency band:: 2.4, 5
Networking standards:: IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3af, IEEE 802.11a
Ethernet LAN data rates:: 10, 100, 1000
Transmitting power:: 26 dBmW
2.4 GHz:: Yes
5 GHz:: Yes
Maximum data transfer rate (2.4 GHz):: 300 Mbit/s
Maximum data transfer rate (5 GHz):: 867 Mbit/s
6 GHz:: No

Power

Power over Ethernet (PoE):: Yes
DC voltage range:: 48
Power consumption (max):: 10.5 W

Antenna

Antenna type:: Internal
Antenna gain level (max):: 6 dBi
Antennas quantity:: 2
Antenna features:: Integrated antenna

Certificates

Certification:: FCC, IC, CE, UL, Wi-Fi Certified, Wi-Fi Certified Passpoint

Operational conditions

Operating relative humidity (H-H):: 10 - 90
Storage temperature (T-T):: -30 - 65
Operating temperature (T-T):: -30 - 60
Storage relative humidity (H-H):: 5 - 95

Logistics data

Harmonized System (HS) code:: 85176990

Weight & dimensions

Height:: 240 mm
Width:: 277 mm
Depth:: 50 mm

Security

Security algorithms:: 64-bit WEP, SSID, 128-bit WEP
Number of SSID supported:: 16

Ports & interfaces

WAN connection:: Ethernet (RJ-45)
USB 2.0 ports quantity:: 0
Ethernet LAN (RJ-45) ports:: 2
DC-in jack:: Yes

Packaging content

Quantity per pack:: 1 pc(s)

Design

Cable lock slot:: Yes
LED indicators:: Power
Product colour:: White
Placement:: Pole
