Single mechanical suction cup Distar TD-DI 6313

Single mechanical suction cup Distar TD-DI 6313 is a handheld vacuum-style lifting accessory designed for gripping and moving smooth, non-porous surfaces. The tool provides mechanical suction action for temporary attachment to glass, tiles or sheet materials, enabling controlled positioning, handling and short-distance transport during installation and maintenance tasks. Its compact single-cup design makes it suitable for one-handed operation and for use in confined spaces where larger lifting devices cannot be applied.

Advantages

The single-cup construction offers a simple and reliable way to establish temporary grip on flat, smooth surfaces without the need for power. A mechanical release and activation mechanism allows quick attachment and detachment while maintaining firm hold during handling. The product’s lightweight and portable form factor reduces operator fatigue and supports easier handling of individual panels or panes. Materials and sealing design are chosen to provide repeatable suction performance on compatible substrates.

Suitable for

• Positioning and mounting glass panes during glazing and window installation
• Handling ceramic or porcelain tiles in tiling and renovation work
• Moving metal or plastic sheet panels with smooth, non-porous surfaces
• Short-distance transfers of flat components within workshops or on-site

Key specifications

• Single suction cup design for one-handed use
• Mechanical vacuum generation and release mechanism
• Intended for smooth, non-porous surfaces such as glass, tile and sheet materials
• Compact and lightweight construction for manual handling
• Non-powered operation—no batteries or external power source required

How to use

Clean the target surface to remove dust, grease or loose particles and ensure full contact of the sealing lip. Place the suction cup centrally on the flat surface and operate the mechanical activation lever according to the tool’s design until a firm vacuum grip is achieved. Lift or move the item within the device’s rated handling limits and maintain a steady, controlled motion. To release, operate the release mechanism to break the vacuum seal and remove the cup from the surface. Inspect the sealing lip regularly and keep the tool free of debris to ensure consistent performance.

Usage recommendations

Use this tool only on compatible smooth, non-porous materials; avoid textured, porous or heavily curved surfaces. Verify the condition of the suction seal before each use and do not exceed the handling capacity appropriate for a single-cup lifter. For heavy or irregular loads, use additional lifting devices or professional handling equipment to ensure safety.
