Built-in hood Elica LANE MBL/A/52

Name: Built-in hood Elica LANE MBL/A/52 PRF0165830
Brand: Elica
SKU: 3544896
Price: 219.99 EUR
Availability: InStock

Hot Deals at AiO.lv

Hurry and order now – up to 50% off!

Built-in hood Elica LANE MBL/A/52 — 514×322×283 mm, 550 m³/h max, aluminium grease filter, LED light, 3 speeds

Built-in hood Elica LANE MBL/A/52 Photo 1

Built-in hood Elica LANE MBL/A/52 Photo 2

Built-in hood Elica LANE MBL/A/52 Photo 3

Built-in hood Elica LANE MBL/A/52 Photo 4

Built-in hood Elica LANE MBL/A/52 Photo 5

Built-in hood Elica LANE MBL/A/52 Photo 6

Product data

Keep track of price changes You keep track of price changes

Scan qr code below, or type in manually: {{secretKey}}

Forgot password? Registration

Short description

Elica LANE MBL/A/52 is a built-in kitchen hood with stainless steel housing and black finish, sized 514×322×283 mm. It offers up to 550 m³/h extraction (boost 650 m³/h), three speeds plus intensive mode, aluminium grease filter and front LED lighting (3500 K, 7 W). Suitable for ducted or recirculating installation; low noise from 49 dB and energy class B.

Available for order: 5 pcs.

Warranty: 2 Years

SKU: 3544896

Manufacturer: Elica

Learn more

Deliver the order:

{{ userCountryName }}

to the Customer Service Center at Kengaraga 2b, Riga

22.06.2026 {{selectedOffer.officeDeliveryString}}

free

All delivery methods Hide details

Customer service center

2b. Kengaraga str., Riga, Latvia, LV-1063

22.06.2026 {{selectedOffer.officeDeliveryString}}

free

Courier Delivery Please note that in case of a large parcel additional delivery costs may apply!

29.06.2026 {{selectedOffer.courierDeliveryString}}

From 8.46 € (Weight: 9.96 kg)

More about delivery methods

pay in 3 equal parts

today

0 €

afterward

3 mth. х 73.33 €

overpayment

0 €

All payment Methods Hide details

All payment Methods:

Bank transfer, Bank cards on-line, Apple Pay, Google Pay, Installment

36 months installment: from 6.11 euros per month

More about payment methods

You saving {{productBundleYouSave | formatAmount}}

Product information

Description

The Elica LANE MBL/A/52 (PRF0165830) is a 60 cm built-in cooker hood in black designed for installation inside a kitchen cabinet, remaining largely invisible while providing high extraction performance. It supports both ducted and recirculating operation (recirculation requires charcoal filter CFC0140343 or regeneratable filter CFC0162221) and is available in white or stainless steel finishes and in 60 cm or 80 cm widths. The hood features perimeter aspiration to increase the effective suction area and a patented mounting system that allows installation into the cabinet using two side clips and only two screws in under one minute.

Advantages

The LANE hood delivers up to 550 m³/h maximum extraction power with a fluid dynamic efficiency class B and maintains a low noise profile for its class. Its aluminium grease filter and LED lighting (7 W) support effective grease capture and energy-efficient illumination. The compact built-in design (width 514 mm, height 322 mm, depth 283 mm) integrates with minimalist kitchens while offering straightforward button controls and simple, fast installation thanks to the patented mounting system.

Suitable for

Small to medium kitchens requiring a built-in, discreet extractor
Users who prefer recirculation or ducted extraction options
Kitchens with minimalist cabinetry where the hood should remain hidden

Key specifications

Width: 514 mm
Maximum extraction power: 550 m³/h
Noise level: 65 dB
Type: Built-in (встроенный)
Grease filter: Aluminium
Energy efficiency class: B
Control type: Buttons
Bulb type: LED, 7 W
Motor power: 257 W
Annual energy consumption: 69 kWh
Colour: Black
Height: 322 mm
Depth: 283 mm

How to use

Install the hood inside a suitably sized kitchen cabinet following the mounting system instructions: engage the two side clips and secure with the two screws supplied to fix the unit in place. Choose ducted extraction to vent air outside or fit the charcoal filter CFC0140343 or regeneratable filter CFC0162221 for recirculating operation. Operate the hood using the front buttons to select the required extraction level and switch on the LED light when needed. Clean the aluminium grease filter regularly according to the manufacturer’s instructions to maintain performance.

Usage recommendations

For best performance, use ducted extraction when possible; if recirculating, replace or regenerate the charcoal filter as recommended. Clean the aluminium grease filter at regular intervals and check that the cabinet installation leaves adequate air pathways for the perimeter aspiration to function effectively.

Specifications

Width:: 514 mm
Maximum extraction power:: 550 m³/h
Noise level: Not only energy saving helps to protect the environment but also noise level reduction. Noise level reduction up to 3 dB really means noise level reduction in 2 times. For example, a device with noise level 39 dB (А) will be two times quieter than a devise with a noise level 42 dB (А). Energy-saving certificate that shows noise level plays the role of an additional objective indicator basing on which You can successfully choose a product.: 65 dB
Type:: Встроенный
Grease filter type:: Aluminium
Energy efficiency class: Rating of how efficiently a device uses energy, affecting power consumption and costs.: B
Control type:: Buttons
Bulb type:: LED
Product colour:: Black
Height:: 322 mm
Depth:: 283 mm

All features

Design

Type:: Встроенный
Control type:: Buttons
Product colour:: Black
Housing material:: Stainless steel
Exhaust connection diameter:: 150 mm
Exhaust location:: Top
Display type:: LED

Filtering

Grease filter type:: Aluminium

Power

Energy efficiency class: Rating of how efficiently a device uses energy, affecting power consumption and costs.: B
Annual energy consumption: Energy consumption of XYZ kW/h per year is based on measurements calculated under standard conditions within 24 hours. Actual power consumption depends on the use of the device and its location.: 69 kWh
Motor power:: 257 W
Energy efficiency class (old):: B

Performance

Noise level: Not only energy saving helps to protect the environment but also noise level reduction. Noise level reduction up to 3 dB really means noise level reduction in 2 times. For example, a device with noise level 39 dB (А) will be two times quieter than a devise with a noise level 42 dB (А). Energy-saving certificate that shows noise level plays the role of an additional objective indicator basing on which You can successfully choose a product.: 65 dB
Number of speeds:: 3
Type of extraction:: Ducted/Recirculating
Intensive speed:: Yes
Maximum extraction power:: 550 m³/h
Minimal distance from hob:: 500 cm
Minimum distance from electric hob:: 500 mm
Minimum distance from gas hob:: 750 mm
Noise level (low speed):: 49 dB
Noise level (high speed):: 65 dB
Boost function: The booster temporarily increases power for rapid heating.: Yes
Fluid dynamic efficiency class:: B
Lighting efficiency class:: A
Grease filtering efficiency class:: D
Boost position air extraction power:: 650 m³/h

Weight & dimensions

Width:: 514 mm
Height:: 322 mm
Depth:: 283 mm
Height (max):: 322 mm

Packaging data

Package weight:: 1120 g
Package depth:: 340 mm
Package height:: 388 mm
Package width:: 575 mm

Other features

Country of origin:: Italy
Net weight:: 9400 g
Airflow:: 650 m³/h
Noise level (max):: 65 dB

Logistics data

UK Trade Tariff code:: 8414600000

Lighting

Bulb power:: 7 W
Bulb type:: LED
Number of bulbs:: 1 bulb(s)
Lighting position:: Front
Colour temperature:: 3500 K
