header-product Built-in Elica Hidden IX/A/90, Ducted, Noise Level: 49 dB

Built-in Elica Hidden IX/A/90, Ducted, Noise Level: 49 dB

Built-in Elica Hidden IX/A/90 Photo 1
Built-in Elica Hidden IX/A/90 Photo 2
Built-in Elica Hidden IX/A/90 Photo 3
Built-in Elica Hidden IX/A/90 Photo 4
Built-in Elica Hidden IX/A/90 Photo 1
Built-in Elica Hidden IX/A/90 Photo 2
Built-in Elica Hidden IX/A/90 Photo 3
Built-in Elica Hidden IX/A/90 Photo 4
Out of stock.
View similar!

Short description

Elica Hidden IX/A/90 is a built-in ducted extractor hood with a maximum extraction power of 475 m³/h. It operates at a noise level of 49 dB on low speed. The unit features a stainless steel housing and a 7 W LED bulb. Dimensions: 900 mm width, 290 mm depth, and 339 mm height. Connected load is 262 W.
Warranty: 2 Years
SKU: 4614687
Manufacturer: Elica
delivery
Information regarding the items availability for purchase will be posted on this site
price
Item cost information will be published on this site
Together cheaper
{{product.price | formatAmount}}
{{product.title}}
{{productBundle.reference.specialPrice | formatAmount}}
{{productBundle.title}}
{{productBundlePreviousPrice | formatAmount}}
{{productBundleSpecialPrice | formatAmount}}

You saving {{productBundleYouSave | formatAmount}}

Product information

Description

Elica Hidden IX/A/90 is a built-in ducted extractor hood designed for kitchens where attention to detail and discreet integration are priorities. The model combines a central stainless steel or glass panel with LED diffuse lighting and touch controls to provide functional ventilation within a streamlined, low-profile housing. Available finishes include stainless steel and stainless steel with white glass. Dimensions: 900 mm width, 290 mm depth, 339 mm height. Maximum extraction power: 475 m³/h. Connected load: 262 W. Noise level on low speed: 49 dB. Energy efficiency class: B.

Advantages

The Elica Hidden IX/A/90 offers a compact built-in design that conceals ventilation components while maintaining effective extraction performance. Touch controls and a 7 W LED light provide simple operation and uniform illumination over the cooktop. The low-profile stainless steel construction and optional white glass center panel suit modern kitchen layouts and facilitate easy cleaning.

Suitable for

  • Integrated kitchen installations requiring a concealed extractor hood
  • Medium-sized kitchens where up to 475 m³/h extraction power is sufficient
  • Design-focused kitchens that need a low-profile stainless steel or glass finish

Key specifications

  • Width: 900 mm
  • Depth: 290 mm
  • Height: 339 mm
  • Maximum extraction power: 475 m³/h
  • Noise level (low speed): 49 dB
  • Connected load: 262 W
  • Energy efficiency class: B
  • Control type: Touch
  • Bulb type: LED (7 W)
  • Colour/finish: Stainless steel or stainless steel with white glass

How to use

Install the hood as a built-in unit into the kitchen cabinet space above the cooktop and connect it to the ducting system for external ventilation according to local regulations. Use the touch controls to switch the hood on, adjust fan speed and operate the LED light. For typical cooking, start the hood shortly before heating and leave it running for a few minutes after cooking to clear residual fumes.

Usage recommendations

Clean removable grease filters regularly and wipe the exterior stainless steel or glass surfaces with a soft damp cloth; replace any non-washable filters per the manufacturer’s instructions. For best performance, ensure ducting is straight and as short as possible and service the unit according to the maintenance schedule.

Specifications

Width:
900 mm
Maximum extraction power:
475 m³/h
Type:
Встроенный
Energy efficiency class: Rating of how efficiently a device uses energy, affecting power consumption and costs.
B
Control type:
Touch
Bulb type:
LED
Product colour:
Stainless steel
Height:
339 mm
Depth:
290 mm
All features

Design

Type:
Встроенный
Control type:
Touch
Product colour:
Stainless steel
Housing material:
Stainless steel
Exhaust connection diameter:
150 mm
Exhaust location:
Top

Power

Energy efficiency class: Rating of how efficiently a device uses energy, affecting power consumption and costs.
B
Connected load:
262 W

Performance

Number of speeds:
3
Type of extraction:
Ducted
Maximum extraction power:
475 m³/h
Noise level (low speed):
49 dB
Noise level (high speed):
65 dB
Pressure (Pa):
530

Weight & dimensions

Width:
900 mm
Height:
339 mm
Depth:
290 mm
Height without chimney:
60 mm

Other features

Country of origin:
Italy

Logistics data

Commodity Classification Automated Tracking System (CCATS):
8414600000

Lighting

Bulb power:
7 W
Bulb type:
LED

Similar products

{{product.title}} Show details Hide details

{{highlightedFeature.featureTitle}}:

{{getProductFeatureValueById(product, highlightedFeature.featureId)}}

{{product.price | formatAmount}}
Might be useful
{{product.manufacturerName}}
{{product.categoryName}}
{{product.title}}
{{product.specialPrice}}
{{product.price}}

Energy label

Energy label
T-MLX47367
Model

Device manufacturer code

Elica
Manufacturer

Device manufacturer

B
Energy efficiency class

Rating of how efficiently a device uses energy, affecting power consumption and costs.
