Elo Touch Solutions I-Series 3.0 All-in-One PC Intel Celeron 7305L 23.8" Touchscreen 8GB RAM 256GB SSD Windows 11 IoT Enterprise Black

AC adapter input voltage:

100 - 240

AC adapter frequency:

50 - 60

AC adapter power:

180 W

RMS rated power: RMS (Root mean square) is a measure of the continuous power required by a device, in particular audio amplifiers and loudspeakers.

4 W

Power consumption (off):

0.5 W

Power cord included:

Yes

Number of SSDs installed:

1

Memory form factor: Design of the memory e.g. 240-pin DIMM, SO-DIMM.

DIMM/SO-DIMM

On-board graphics card model: "Graphic adapter" is the hardware that produces images on a display. "On-board" means that the graphics adapter is intergrated inside the motherboard.

Intel® UHD Graphics

Discrete graphics card model: A graphics adapter (often known as a video card) generates images for a display. A discrete graphics adapter plugs into the motherboard, and usually produces much better graphics than an integrated graphics adapter. There are various models of discrete graphics adapters.

Not available

Market positioning: Under which category can the device be positioned in the market, e.g. camera phone.

Business

On-board graphics card: Graphics hardware which is built into the motherboard or CPU, as opposed to a separate graphics adapter (video card). On-board graphics uses CPU and RAM for graphics processing.

Yes

Memory layout (slots x size): The slots and size of the memory for the CPU.

1 x 8

Native aspect ratio: The aspect ratio is the ratio of the width of an image to its height. The native aspect ratio is the one which the projector/display is particularly designed for. Images shown in native aspect ratio will utilize the entire resolution of the display and achieve maximum brightness. Images shown in other than native aspect ratio will always have less resolution and less brightness than images shown in native aspect ratio.

16:9

HD type: Type of supported High Definition (e.g. Full HD, 4K Ultra HD).

Full HD

Weight (without stand):

7100 g

Height (without stand):

352 mm

Width (without stand):

571.2 mm

Depth (without stand):

39 mm

Product type: The sub-category of the product.

All-in-One PC

Panel type:

TFT

Number of storage drives installed: Amount of storage drives built into the device.

1

Processor cache type:

Smart Cache

USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity:

0

USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: Number of USB 3.1 (3.1 Gen 2) ports with Type-C connector. USB 3.1 (3.1 Gen 2) is USB interface version which supports transfer rate up to 10 Gbit/s (SuperSpeed+). USB Type-C connector has symmetrical design architecture and compatible with Thunderbolt 3 interface.

0

Top Wi-Fi standard: Connection of this device is done via Wi-Fi in a high standard.

Wi-Fi 6 (802.11ax)

Discrete graphics card:

No

On-board graphics card family:

Intel® UHD Graphics

Total SSDs capacity:

256 GB

Processor base power:

15 W

Maximum turbo power:

28 W

On-board GPU manufacturer:

Intel

Other features

Memory slots: Number and type of memory expansion slots, including connector and memory module descriptions.

2

Camera

Built-in camera: The product has an integrated camera.

No

Technical details

Compliance certificates: Indicates which regulatory, safety, and environmental standards the product complies with, as verified by recognized authorities or certification bodies.

CB, CCC, Federal Communications Commission (FCC), Norma Oficial Mexicana (NOM), RCM, RoHS, State Radio Regulation of China (SRRC), UKCA, VCCI, CE, Industry Canada (IC)

Sustainability

Sustainability certificates:

ENERGY STAR

Packaging content

Quick start guide: Instructions, either online, as a computer program or in paper form, to allow you to set up and start using the product quickly.

Yes

Packaging data

Package weight: Weight of the packaged product.

9700 g

Package height: The distance from the top to the bottom of the packaging.

188 mm

Package depth: The distance from the front to the back of the packaging.

529 mm

Package width: The distance from one side of the packaging to the other.

697 mm

Ergonomics

Mean time between failures (MTBF): Statistical model used to indicate product/mechanism reliability; expressed in hours and percentage of duty cycle. This number (in hours) does not indicate the mean time before failure for a single unit/mechanism.

50000 h

Panel mounting interface: The product can be used wih VESA mounting interfaces.

100 x 100

VESA mounting:

Yes

Wall mountable: The product can be mounted on (attached to ) a wall.

Yes

Operational conditions

Operating relative humidity (H-H):

20 - 80

Storage temperature (T-T): The minimum and maximum temperatures at which the product can be safely stored.

-20 - 60

Operating temperature (T-T): The minimum and maximum temperatures at which the product can be safely operated.

0 - 35

Storage relative humidity (H-H):

5 - 95

Power

Power consumption (standby): The amount of electricity that is consumed when the product is on standby.

5 W

AC adapter output voltage:

24

Software

Operating system architecture: The way in which the operating system of a computer/smartphone (32-bit/64-bit) is set up.

64-bit

Operating system installed: Type of operating system on a device e.g. IOS on Apple devices, Android for mobile devices.

Windows 11 IoT Enterprise

Performance

Trusted Platform Module (TPM) version:

2.0

Trusted Platform Module (TPM):

Yes

Design

Product colour: The colour e.g. red, blue, green, black, white.

Black

Ports & interfaces

Headphone outputs: Number of sockets /ports where headphones are connected.

1

HDMI ports quantity: The number of sockets (ports) for HDMI connections. HDMI (High-Definition Multimedia Interface) is a compact audio/video interface for transferring uncompressed video data and compressed/uncompressed digital audio data from a HDMI-compliant device ("the source device") to a compatible computer monitor, video projector, digital television, or digital audio device. HDMI is a digital replacement for existing analog video standards.

0

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity:

4

USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: Number of USB 3.0 (3.1 Gen 1) ports with Type-C connector. USB 3.0 (3.1 Gen 1) is USB interface version which supports transfer rate up to 5 Gbit/s (SuperSpeed). USB Type-C connector has symmetrical design architecture and compatible with Thunderbolt 3 interface.

1

Ethernet LAN (RJ-45) ports: Number of Ethernet LAN (RJ-45) ports (connecting interfaces) in the device. Ethernet LAN (RJ-45) ports allow a computer to connect to the ethernet.

1

Network

Wi-Fi standards: The type of wireless local area network (LAN). It can be ad-hoc, where units in a network communicate peer-to-peer, or Infrastructure, where units communicate with each other via an access point A LAN interconnects computers in a small area e.g. home, school or office.

802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)

Wi-Fi: Popular technology that allows an electronic device to exchange data or connect to the internet wirelessly using radio waves.

Yes

Bluetooth version: The type of bluetooth technology in the product e.g. Bluetooth Smart (v4.0).

5.3

Bluetooth: Bluetooth is a low-power radio technology developed to replace the cables and wires currently used to link or connect electronic devices such as personal computers, printers, and a wide variety of handheld devices including mobile phones. Because it uses radio-wave connectivity, a Bluetooth-enabled device has a constant, established connection to whatever browser it uses. This saves the user the trouble of logging on to check for emails or news updates, for example.

Yes

Ethernet LAN data rates: The different speed levels of the Ethernet LAN connection.

10, 100, 1000

Ethernet LAN: An Ethernet LAN (Local Area Network) interface is present, for a wired conection via a cable.

Yes

Multimedia

Optical drive type: An optical drive uses laser to read optical discs such as CDs, DVDs and Blu-Ray. Some types of optical drive are: CD ROM drive, CR-RW (CD writer) drive, DVD-ROM.

No

Number of speakers: The quantity of speakers included in/with the product.

2

Built-in speaker(s): The device contains speaker(s) to produce sound.

Yes

Storage

SSD form factor: The size of the solid-state drive, given in inches

M.2

SSD interface: The type of interface(s) with which the Solid State Drive is connected to other hardware.

M.2

SSD capacity:

256 GB

NVMe: NVM Express (NVMe) or Non-Volatile Memory Host Controller Interface Specification (NVMHCIS) is an open logical device interface specification for accessing non-volatile storage media attached via a PCI Express (PCIe) bus. NVM Express, as a logical device interface, has been designed to capitalize on the low latency and internal parallelism of solid-state storage devices.

Yes

Number of storage drives supported: How many storage drives can be fit into the product at once.

1

Storage media: Used for the storage of data e.g. HDD (hard disk drive), SSD (solid-state drive).

SSD

Total storage capacity: The total amount of data that can be stored on the device.

256 GB

Memory

Memory clock speed: The frequency at which the memory (e.g. RAM) runs.

4800 MHz

Memory slots type: A memory slot, also known as a memory socket or RAM slot, is what allows computer memory (RAM) to be inserted into the computer. Depending on the motherboard, there will usually be 2 to 4 memory slots (sometimes more on high-end motherboards). The most common types of RAM are SDRAM and DDR for desktop computers and SODIMM for laptop computers, each having various types and speeds.

SO-DIMM

Maximum internal memory: The maximum internal memory which is available in the product.

32 GB

Internal memory type: The type of internal memory such as RAM, GDDR5.

DDR5-SDRAM

Internal memory: A computer's memory which is directly accessible to the CPU.

8 GB

Processor

Processor cache:

8 MB

Efficient-core Max Turbo Frequency:

1.1 GHz

Performance-core Max Turbo Frequency:

1.1 GHz

Efficient cores:

4

Performance cores:

1

Processor frequency: The speed that the microprocessor executes each instruction or each vibration of the clock. The CPU requires a fixed number of clock ticks, or cycles, to execute each instruction. The faster the clocks rate, the faster the CPU, or the faster it can execute instructions. Clock Speeds are usually determined in MHz, 1 MHz representing 1 million cycles per second, or in GHz, 1 GHz representing 1 thousand million cycles per second. The higher the CPU speed, the better a computer will perform.

1.1 GHz

Processor boost frequency: The turbo boost is an automatic, managed accelleration of the processor when one of the cores is overloaded.

1.1 GHz

Processor threads:

5

Processor cores: The number of central processing units ('cores') in a processor. Some processors have 1 core, others have 2 (e.g. Intel Core Duo) or more (e.g. the Intel Xeon E7-2850 has 10 cores).

5

Processor model: The model number for the processor in a computer.

7305L

Processor family: A family of processors is a group of processors produced by one company over a short period of time e.g. Intel Pentium processors.

Intel® Celeron®

Processor manufacturer: The manufacturer that produced the processor.

Intel

Display

Viewing angle, horizontal: Maximum horizontal angle at which a display can be viewed with acceptable visual performance.

178 °

Viewing angle, vertical: Maximum vertical angle at which a display can be viewed with acceptable visual performance.

178 °

Display brightness: Brightness is the amount of radiating light emitted from the screen. The brightness rating is measured in candellas per square meter, commonly known as 'nits'.

250 cd/m²

Response time: The response time is the time difference between the moment that a source (for example a video card) sends a signal and that equipment (for example a monitor) receives or display the signal. (Used abbreviations: R/F = Rise and Fall.)

16 ms

Screen shape:

Flat

Touch technology: Technology of touch sensetive screen e.g. dual-touch.

Multi-touch

LED backlight: A backlight is a form of illumination used in liquid crystal displays (LCDs). One type of backlight is made by LEDs, which can be either white or RGB (red green blue). White LEDs are used most often in notebooks and desktop screens, and in virtually all mobile LCD screens. RGB LEDs for backlighting are found in high-end color proofing displays such as HP DreamColor LP2480zx monitor or selected HP EliteBook notebooks, as well as newer consumer grade displays such as Dell's Studio series laptops which have an optional RGB LED display.

Yes

Touchscreen: A screen of a laptop, smartphone, etc., that responds to touch so you can control the interface using your fingers.

Yes

Display resolution: The number of distinct pixels in each dimension that can be displayed. It is usually quoted as width × height, with the units in pixels: for example, "1024 × 768" means the width is 1024 pixels and the height is 768 pixels. The higher the number of pixels, the sharper the image.

1920 x 1080

Display diagonal: Size of the display for this product, measured diagonally, usually in inches.

23.8 "
