EPM Insulated Ferrule Spade Connector, model E-652-0022 — 1–1.5 mm², pack of 10

EPM E-652-0022 insulated ferrule spade connectors are designed for secure electrical wire terminations where a spade-style contact is required. Each kit contains ten insulated ferrule spade connectors suitable for conductors with cross-sectional areas from 1 to 1.5 mm². The connectors combine a crimpable metal sleeve for reliable electrical contact with an insulating collar to protect against short circuits and to improve handling during installation. They are intended for terminating stranded or solid wires when connecting to screw terminals, terminal blocks, relays or appliance connectors.

Advantages

The insulated ferrule spade design ensures consistent crimp quality and improved mechanical stability compared with bare wire ends. The insulating collar reduces the risk of accidental shorting and provides strain relief at the termination point. Small pack size of ten pieces allows easy inventory management for small installation jobs or maintenance kits. The connectors are compatible with standard crimping tools sized for ferrules and spade terminals.

Suitable for

• Panel wiring and control cabinets requiring spade terminations
• Terminal block and screw terminal connections
• Appliance and equipment internal wiring
• Field repairs and maintenance of electrical installations

Key specifications

• Conductor cross-section: 1–1.5 mm²
• Connector type: insulated ferrule with spade (fork) end
• Pack quantity: 10 pieces
• Suitable for crimping onto stranded and solid conductors
• Insulating collar for electrical isolation and strain relief

How to use

Strip the conductor to the appropriate length recommended for the ferrule sleeve, insert the bare conductor fully into the metal sleeve, and position the insulating collar against the wire insulation. Use a compatible ferrule/spade crimping tool to compress the metal sleeve evenly until a secure mechanical and electrical connection is achieved. After crimping, inspect the connection for firm retention of the conductor and proper alignment of the spade end before inserting into the terminal or fastening with a screw.

Usage recommendations

Use ferrule crimping tools sized for 1–1.5 mm² ferrules to ensure reliable crimps. Confirm compatibility of the spade width with target terminals and avoid over-stripping the conductor. For repeated mechanical stress or vibration-prone applications, verify that the insulating collar and crimp form provide adequate strain relief and consider additional securing measures if required.
