DMX merger EUROLITE DXT-ME PRO with 4 DMX inputs and 1 DMX output

The EUROLITE DXT-ME PRO with 4 DMX inputs and 1 DMX output is a compact DMX merger designed to combine four independent DMX control sources into a single merged DMX stream. It is intended for situations where multiple consoles, controllers, or playback devices need to share control of lighting rigs or stage equipment without complex wiring or manual signal switching. The unit supports standard DMX512 signal levels and provides a single DMX output that reflects the merged data from all connected inputs.

Advantages

The DMX merger reduces setup time and simplifies cabling by consolidating up to four DMX sources into one output. It enables conflict resolution and source prioritization so that multiple operators can control different aspects of a show or hand over control between devices. The compact form factor and straightforward connectivity make it suitable for permanent installations as well as touring and rental environments. The device helps maintain reliable DMX distribution while minimizing the need for additional splitters or manual changeovers.

Suitable for

• Concerts and live performances where multiple consoles are used
• Theatre productions requiring coordinated control from several devices
• Permanent installations with separate control sources (e.g., house and show control)
• Rental companies and touring rigs that need flexible signal management
• Event setups that must merge backup or priority control lines

Key specifications

• Input channels: Four separate DMX512 inputs
• Output: Single merged DMX512 output
• Signal handling: Merges multiple DMX data streams into one consolidated output
• Compatibility: Works with standard DMX512 lighting consoles and controllers
• Form factor: Compact rack- or flight-case-friendly housing
• Controls: Front-panel selection and priority controls for source management

How to use

Connect each DMX source to one of the four DMX input ports and run the DMX output to your dimmer pack, fixture network, or DMX splitter. Use the front-panel controls to assign priorities or define how conflicting channels are resolved according to the unit's operating modes. Verify continuity and proper termination in the DMX chain; use a terminator at the end of the final DMX run if required. Power the unit according to the manufacturer's instructions and confirm that the merged output behaves as expected before the live event.

Usage recommendations

For predictable behavior, configure source priorities during system setup and test all control scenarios before performance. Where possible, label input lines and maintain a clear signal flow diagram to simplify troubleshooting in multi-operator environments.
