Threaded Insert DIES M8 DIN223 FANAR

DIES M8 DIN223 by FANAR is a threaded insert intended for creating or repairing M8 metric internal threads that conform to DIN 223. The insert is supplied as a single unit and is designed for use in machining, assembly and repair operations where a standardized M8 internal thread is required in metal or compatible materials. The product is suitable for professional workshop environments as well as maintenance and fabrication tasks that demand reliable, standardized thread geometry.

Advantages

The threaded insert provides a precise M8 thread profile consistent with DIN 223, enabling interchangeability and compatibility with standard M8 bolts and fasteners. Its single-piece supply format makes inventory and usage straightforward. The design supports repair of worn or damaged threads and the creation of new, accurate internal threads in components that require repeatable fastening performance. Manufactured by FANAR, the insert adheres to recognized metric thread standards, which simplifies specification and reduces the need for custom thread solutions.

Suitable for

• Repairing worn or damaged M8 internal threads in metal components
• Creating new M8 threads in machined parts and housings
• Assembly workplaces where standardized M8 fastenings are required
• Maintenance and fabrication tasks in workshops and industrial settings

Key specifications

• Thread size and form: M8 metric internal thread to DIN 223
• Configuration: single threaded insert unit for internal thread creation or repair
• Intended material use: metal and compatible substrates suitable for threading
• Application area: machining, assembly, repair and maintenance operations

How to use

Select an appropriate hole or preparatory operation to match the insert’s requirements, then machine or drill the parent material to the recommended diameter for DIN 223 M8 inserts. Install the insert into the prepared hole following standard fitting practices for threaded inserts, ensuring correct alignment and seating to achieve the specified M8 thread geometry. After installation, verify thread engagement with a standard M8 bolt to confirm proper fit and functionality.

Usage recommendations

Use appropriate cutting fluids and machining speeds when preparing holes in metal to maintain dimensional accuracy. Verify compatibility of the parent material with threaded insert installation methods and ensure the working environment observes standard safety procedures for machining and assembly tasks.
